Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NCX
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CROSSWAY TFS III, material: aluminium, 700x50C max. wheelsize, 135x9mm axle standard, BSA bottom bracket standard
Suspension Fork
Suntour NCX D-RL, Coil, 63mm suspension travel, Remote Lockout, 700x50C max. wheelsize
Drivetrain
Rear Derailleur
Shimano XT Shadow
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore
Cassette
Shimano HG500, 11-34 teeth, 10 speed
Crank
FSA Alfa Drive, 48-36-26 teeth, 170 mm-XXS/XS/S, 175 mm-M/XL
Bottom Bracket
BSA, threaded
Chain
KMC X10
Pedals
VP VPE-891
Wheels
Front Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TX505, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP TK, 20mm inner width, 17mm height, material: aluminium
Spokes
Black stainless
Tires
Maxxis Overdrive II, 700x40C, fold, reflective stripe, Silkworm
Brakes
Brakes
Shimano MT-400, 2 piston
Brake Levers
Shimano MT-200
Cockpit
Handlebar
MERIDA COMP CC, material: aluminium, 660mm width, 25mm rise
Headset
MERIDA M2340 Neck
Seat
Saddle
MERIDA EXPERT TK, V-mount
Seatpost
MERIDA COMP CC, material: aluminium, 30.9mm diameter, 12mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.59 mm | 1.6 mm | 1.61 mm | 1.63 mm | 1.65 mm |
| Front Center | 625 mm | 630 mm | 634 mm | 645 mm | 653 mm | 674 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 41 mm | 41 mm |
| Trail | 79 mm | 79 mm | 76 mm | 76 mm | 74 mm | 74 mm |
| Stack | 627 mm | 627 mm | 638 mm | 652 mm | 674 mm | 702 mm |
| Reach | 389 mm | 394 mm | 400 mm | 406 mm | 413 mm | 425 mm |
| Top Tube Length | 567 mm | 572 mm | 587 mm | 597 mm | 617 mm | 637 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 390 mm | 430 mm | 470 mm | 510 mm | 550 mm | 590 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 130 mm | 130 mm | 140 mm | 155 mm | 175 mm | 205 mm |
| Chainstay Length | 467 mm | 467 mm | 467 mm | 467 mm | 467 mm | 467 mm |
| Wheelbase | 1083 mm | 1088 mm | 1092 mm | 1103 mm | 1111 mm | 1132 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 685 mm | 720 mm | 755 mm | 789 mm | 824 mm | 861 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
CROSSWAY 500 is part of the Merida Crossway model. 210 bikes variations carry this model name so far. You can easily view all of the Merida Crossway bikes models from 2023, here.
Model range prices
Merida CROSSWAY 20-D (L) 2023 is the cheapest bike model and costs 560$. Merida CROSSWAY 300 2023 is the most expensive one and costs 1077$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Hybrid bikes
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Merida released this model in 2023, its price was 955$. Comparing the average cost of a Hybrid bike to this one, you will see that CROSSWAY 500 price is 69.93% more expensive.
CROSSWAY 500 components
Fork
The CROSSWAY 500 comes factory-installed with the Suntour NCX fork. This has a travel range of 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
As for the wheels, Merida CROSSWAY 500 2023, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
