Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NCX
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
145cm - 160cm
SM
155cm - 170cm
MD
161cm - 180cm
LG
171cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CROSSWAY TFS, material: aluminium, 700C wheelsize, 135x9mm axle standard, BSA bottom bracket standard
Suspension Fork
Suntour NCX D-RL, Coil, 63mm suspension travel, Remote Lockout
Drivetrain
Rear Derailleur
Shimano XT Shadow
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore
Cassette
Shimano HG500, 11-34 teeth, 10 speed
Crank
Shimano Deore, 48-36-26 teeth, 170 mm-XXS/XS/S, 175 mm-M/XL
Bottom Bracket
Shimano BB52 BSA
Chain
KMC X10
Wheels
Front Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TX505, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP TK, 20mm inner width, 17mm height, material: aluminium
Spokes
Black stainless
Tires
Maxxis Overdrive II, 700x40C, fold, reflective stripe, Silkworm
Brakes
Brakes
Shimano MT-400
Brake Levers
Shimano MT-200
Cockpit
Handlebar
MERIDA COMP CC, material: aluminium, 660mm width, 25mm rise
Headset
MERIDA M2340 Neck
Seat
Saddle
MERIDA EXPERT TK, V-mount
Seatpost
MERIDA COMP CC, material: aluminium, 30.9mm diameter, 12mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.56 mm | 1.56 mm | 1.57 mm | 1.6 mm | 1.62 mm |
| Front Center | 629 mm | 634 mm | 638 mm | 649 mm | 658 mm | 679 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 47 mm |
| Trail | 75 mm | 75 mm | 72 mm | 72 mm | 68 mm | 67 mm |
| Stack | 618 mm | 618 mm | 629 mm | 644 mm | 665 mm | 693 mm |
| Reach | 392 mm | 397 mm | 403 mm | 409 mm | 416 mm | 427 mm |
| Top Tube Length | 567 mm | 572 mm | 587 mm | 597 mm | 617 mm | 637 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 390 mm | 430 mm | 470 mm | 510 mm | 550 mm | 590 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 130 mm | 130 mm | 140 mm | 155 mm | 175 mm | 205 mm |
| Chainstay Length | 467 mm | 467 mm | 467 mm | 467 mm | 467 mm | 467 mm |
| Wheelbase | 1087 mm | 1092 mm | 1096 mm | 1107 mm | 1116 mm | 1137 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 686 mm | 719 mm | 752 mm | 786 mm | 821 mm | 856 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 149 cm | 160 cm | 170 cm | 180 cm | 190 cm | cm |
Model Overview
CROSSWAY 600 completes the Merida Crossway model. 210 bikes variations carry this model name so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Merida CROSSWAY 10-V 2020 is the most economical model, with a starting price of 487$. Merida CROSSWAY URBAN 300 2020 on the other hand costs 1010$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Hybrid bikes average price
If you want to purchase a solid Hybrid bike, it is important to know that the average cost is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Hybrid bikes average weight
Hybrid bikes weigh an average of 13.85 kg (30.53 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
CROSSWAY 600 weighs 12.51 kg (27.58 lbs) and is considerably lighter than the average. In conclusion, the average Hybrid bike weighs 10.71% more than CROSSWAY 600.
CROSSWAY 600 components
Fork
The CROSSWAY 600 comes factory-installed with the SunTour NCX fork. This has a travel range of 63mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When leaving the production line, the CROSSWAY 600 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The CROSSWAY 600 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
