Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NCX
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
145cm - 160cm
SM
155cm - 170cm
MD
161cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CROSSWAY TFS L, material: aluminium, 700C wheelsize, 135x9mm axle standard, BSA bottom bracket standard
Suspension Fork
Suntour NCX D-RL, Coil, 63mm suspension travel, Remote Lockout
Drivetrain
Rear Derailleur
Shimano XT Shadow
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore
Cassette
Shimano HG500, 11-34 teeth, 10 speed
Crank
Shimano Deore, 48-36-26 teeth, 170 mm-XS/S, 175 mm-M/XL
Bottom Bracket
Shimano BB52 BSA
Chain
KMC X10
Wheels
Front Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TX505, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP TK, 20mm inner width, 17mm height, material: aluminium
Spokes
Black stainless
Tires
Maxxis Overdrive II, 700x40C, fold, reflective stripe, Silkworm
Brakes
Brakes
Shimano MT-400
Brake Levers
Shimano MT-200
Cockpit
Handlebar
MERIDA COMP CC, material: aluminium, 660mm width, 25mm rise
Headset
MERIDA M2340 Neck
Seat
Saddle
MERIDA EXPERT TK, V-mount
Seatpost
MERIDA COMP CC, material: aluminium, 30.9mm diameter, 12mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.56 mm | 1.56 mm | 1.57 mm | 1.6 mm |
| Front Center | 629 mm | 634 mm | 638 mm | 649 mm | 658 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 75 mm | 75 mm | 72 mm | 72 mm | 68 mm |
| Stack | 618 mm | 618 mm | 629 mm | 644 mm | 665 mm |
| Reach | 392 mm | 397 mm | 403 mm | 409 mm | 416 mm |
| Top Tube Length | 567 mm | 572 mm | 587 mm | 597 mm | 617 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 390 mm | 430 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 130 mm | 130 mm | 140 mm | 155 mm | 175 mm |
| Chainstay Length | 467 mm | 467 mm | 467 mm | 467 mm | 467 mm |
| Wheelbase | 1087 mm | 1092 mm | 1096 mm | 1107 mm | 1116 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 657 mm | 657 mm | 657 mm | 658 mm | 658 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 149 cm | 160 cm | 170 cm | 180 cm | cm |
Model Overview
CROSSWAY L 600 is part of the Merida Crossway model. 210 bikes variations carry this model name so far. You can easily view all of the Merida Crossway bikes models from 2020, here.
Model range prices
Merida CROSSWAY 10-V 2020 is the cheapest bike model and costs 487$. Merida CROSSWAY URBAN 300 2020 is the most expensive one and costs 1010$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Hybrid bikes
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Hybrid bikes
If we make a quick analysis of the average weight of a Hybrid bike, we get 13.85 kg (30.53 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Merida CROSSWAY L 600 it’s weighing 12.39 kg (27.32 lbs). At this weight, is considerably lighter than average. To sum up, it’s 11.78% lighter than the average weight of Hybrid bikes.
CROSSWAY L 600 components
Fork
This bike has the SunTour NCX fork installed. The fork’s travel is 63mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
As for the wheels, Merida CROSSWAY L 600 2020, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida CROSSWAY L 600 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
