Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset NX, FSA -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CROSSWAY URBAN TFS LADY
Suspension Fork
Lightweight aluminium fork with disc mounts
Drivetrain
Rear Derailleur
SRAM NX 11
Shift Levers
SRAM NX 11 speed trigger
Cassette
Sunrace CSMS8, 11 speed, 11-42 teeth
Crank
FSA Comet 36 teeth
Chain
KMC X11-1
Wheels
Front Hub
Alloy hubs with allen key security fixing and centerlock
Rear Hub
Alloy hubs with allen key security fixing and centerlock
Rims
MERIDA Urban
Spokes
Black stainless
Tires
Maxxis Overdrive 35c with reflective strip
Brakes
Brakes
Shimano M315 hydraulic disc, 160mm rotors
Brake Levers
Shimano M315
Cockpit
Handlebar
MERIDA Comp 660mm wide 25mm rise
Headset
MERIDA M2341
Seat
Saddle
Crossway comfort
Seatpost
MERIDA Comp 12mm, 27.2mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.45 mm | 1.43 mm | 1.42 mm | 1.39 mm |
| Front Center | 630 mm | 630 mm | 640 mm | 645 mm | 655 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 73 mm | 73 mm | 73 mm | 69 mm | 66 mm |
| Stack | 587 mm | 592 mm | 597 mm | 603 mm | 610 mm |
| Reach | 410 mm | 409 mm | 417 mm | 425 mm | 438 mm |
| Top Tube Length | 582 mm | 582 mm | 592 mm | 607 mm | 622 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 72 ° |
| Seat Tube Length | 390 mm | 430 mm | 470 mm | 510 mm | 540 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 160 mm | 165 mm | 170 mm | 175 mm | 180 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1078 mm | 1078 mm | 1088 mm | 1093 mm | 1103 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 593 mm | 595 mm | 597 mm | 596 mm | 599 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
CROSSWAY URBAN 300 LADY is part of the Merida Crossway model. Merida launched 210 bikes of this model so far. You can easily view all of the Merida Crossway bikes models from 2018, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid bikes average price
If you want to purchase a solid Hybrid bike, it is important to know that the average cost is 562$. However, even though the average price of a Hybrid bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Hybrid bikes
The average weight for Hybrid bikes is 13.85 kg (30.53 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
CROSSWAY URBAN 300 LADY weighs 11.73 kg (25.86 lbs) and is much lighter than the average. In other words, this model is 18.07% lighter than the average Hybrid bike.
CROSSWAY URBAN 300 LADY components
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
As for the wheels, Merida CROSSWAY URBAN 300 LADY 2018, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The CROSSWAY URBAN 300 LADY comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
