Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Altus, Shimano -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CROSSWAY URBAN SPEED
Suspension Fork
Lightweight aluminium fork with disc mounts
Drivetrain
Rear Derailleur
Shimano Altus RD-M370
Front Derailleur
Shimano FD-M371
Shift Levers
Shimano EF505 27 speed EZ-fire shifters
Cassette
Shimano CS-HG200, 9 speed, 11-32 teeth
Crank
Suntour XCM-T418 48-36-26 with chainguard
Chain
KMC M99
Wheels
Front Hub
Shimano TX505 32 hole quick release with centerlock
Rear Hub
Shimano TX505 32 hole quick release with centerlock
Rims
MERIDA aluminium, 32 hole for disc brakes
Spokes
Black steel
Tires
Kenda K1024 38c wire bead
Brakes
Brakes
Shimano EF505 hydraulic disc brakes with 160mm centerlock rotors
Brake Levers
Shimano EF505
Cockpit
Handlebar
MERIDA Speed 660mm wide 30mm rise
Headset
TH888/NO.10
Seat
Saddle
Crossway Sport
Seatpost
MERIDA Speed 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD/LG | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.42 mm | 1.4 mm | 1.39 mm | 1.43 mm | 1.44 mm | 1.5 mm |
| Front Center | 625 mm | 631 mm | 635 mm | 645 mm | 645 mm | 660 mm | 664 mm |
| Rake | 45 mm | 51 mm | 45 mm | 49 mm | 45 mm | 45 mm | 45 mm |
| Trail | 73 mm | 63 mm | 69 mm | 62 mm | 66 mm | 66 mm | 63 mm |
| Stack | 577 mm | 583 mm | 588 mm | 595 mm | 609 mm | 628 mm | 654 mm |
| Reach | 407 mm | 410 mm | 419 mm | 427 mm | 427 mm | 436 mm | 437 mm |
| Top Tube Length | 571 mm | 581 mm | 591 mm | 601 mm | 611 mm | 626 mm | 641 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 440 mm | 460 mm | 480 mm | 520 mm | 550 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72.5 ° |
| Head Tube Length | 150 mm | 155 mm | 160 mm | 165 mm | 180 mm | 200 mm | 225 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1072 mm | 1078 mm | 1082 mm | 1092 mm | 1092 mm | 1107 mm | 1111 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 730 mm | 745 mm | 762 mm | 793 mm | 817 mm | 844 mm | 874 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
CROSSWAY URBAN 40-D is part of the Merida Crossway model. Merida released 210 bikes variations of this model so far. Take a sneak peek at all Merida Crossway bikes models from 2018, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Hybrid bikes average price
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, even though the average price of a Hybrid bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Hybrid bikes
Hybrid bikes have an average weight of 13.85 kg (30.53 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 12.9 kg (28.44 lbs), Merida bike is a bit lighter than average. In conclusion, the average Hybrid bike weighs 7.36% more than CROSSWAY URBAN 40-D.
Overview of components
Fork material
The fork is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
As for the wheels, Merida CROSSWAY URBAN 40-D 2018, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The CROSSWAY URBAN 40-D comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
