Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Metrea -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CROSSWAY URBAN CF3
Suspension Fork
CC Carbon disc 15
Drivetrain
Rear Derailleur
Shimano Metrea
Shift Levers
Shimano Metrea 11
Cassette
Shimano CS-5800-11 11-32
Crank
Metrea 42T [PF]
Chain
KMC X11EL-1
Wheels
Front Hub
Centerlock-15 allen / FoBearing Cen 12 Allen
Rear Hub
Centerlock-15 allen / FoBearing Cen 12 Allen
Rims
MERIDA Urban
Spokes
Black stainless
Tires
Continental Sport contact II
Brakes
Brakes
Shimano Metrea 160
Brake Levers
Shimano Metrea
Cockpit
Handlebar
MERIDA Expert "H" bar OS 440
Headset
Big Conoid S-bearing neck pro
Seat
Saddle
Selle Italy Flite Titanium Nubuck Leather
Seatpost
MERIDA carbon Expert SB15 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 53cm | 56cm | 59cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.44 mm | 1.46 mm | 1.48 mm | 1.5 mm |
| Front Center | 588 mm | 584 mm | 589 mm | 598 mm | 614 mm |
| Rake | 50 mm | 50 mm | 46 mm | 46 mm | 46 mm |
| Trail | 71 mm | 64 mm | 65 mm | 62 mm | 62 mm |
| Stack | 523 mm | 537 mm | 556 mm | 576 mm | 596 mm |
| Reach | 373 mm | 374 mm | 381 mm | 389 mm | 398 mm |
| Top Tube Length | 522 mm | 532 mm | 547 mm | 560 mm | 575 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 560 mm | 590 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 100 mm | 111 mm | 131 mm | 150 mm | 171 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1004 mm | 1000 mm | 1005 mm | 1014 mm | 1030 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 727 mm | 750 mm | 777 mm | 804 mm | 828 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
CROSSWAY URBAN 7000 completes the Merida Crossway model. Merida released 210 bikes variations of this model so far. Take a sneak peek at all Merida Crossway bikes models from 2017, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Hybrid bikes average price
If you want an acceptable Hybrid bike you should know that the average price is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Hybrid bikes
On a deeper look, we notice that the average weight of a Hybrid bike is 13.85 kg (30.53 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
much lighter than average, CROSSWAY URBAN 7000 has a weight of 9.12 kg (20.11 lbs). To sum up, it’s 51.86% lighter than the average weight of Hybrid bikes.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The CROSSWAY URBAN 7000 2017 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The CROSSWAY URBAN 7000 has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
