Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 700c -
Groupset Ultegra, FSA -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CC Lite-D-Single
Suspension Fork
CC Carbon-D
Drivetrain
Rear Derailleur
Shimano Ultegra SS
Front Derailleur
Shimano Ultegra Double
Shift Levers
Shimano Ultegra Dual Control
Cassette
Shimano CS-6800 11-28 11s
Crank
FSA Gossamer Pro Cross 46-36 Mega 11
Bottom Bracket
attached
Chain
KMC X11S
Wheels
Front Hub
Shimano Cyclo Cross Cen
Rear Hub
Shimano Cyclo Cross Cen
Rims
MERIDA XCD Lite [28H]
Spokes
black stainless
Tires
Continental Cyclocross Race 35 fold
Brakes
Brakes
Hayes CX Expert 160 mm / Hayes CX Expert 140 mm
Brake Levers
On Bar Lever additional
Cockpit
Handlebar
MERIDA Road Pro Classic OS
Headset
Orbit X
Seat
Saddle
ProLogo Kappa Evo
Seatpost
Merida Pro H SB15 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 52cm | 55cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.34 mm | 1.41 mm | 1.4 mm | 1.4 mm |
| Bottom Bracket Height | 289 mm | 289 mm | 284 mm | 284 mm | 284 mm |
| Stack | 505 mm | 507 mm | 534 mm | 553 mm | 575 mm |
| Reach | 378 mm | 378 mm | 380 mm | 395 mm | 412 mm |
| Top Tube Length | 515 mm | 520 mm | 545 mm | 566 mm | 589 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 520 mm | 550 mm | 580 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 100 mm | 100 mm | 120 mm | 138 mm | 161 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Cyclo Cross 5 completes the Merida Cyclo model. There are 28 bikes that carry this model name. You can easily view all of the Merida Cyclo bikes models from 2014, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Cyclocross bikes
If you want to purchase a solid Cyclocross bike, it is important to know that the average cost is 2012$. However, this doesn’t mean that if you spend less money on a Cyclocross bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Cyclocross bikes average weight
The average weight for Cyclocross bikes is 8.79 kg (19.38 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 9.68 kg (21.34 lbs), Merida bike is considerably heavier than average. To sum up, it’s 10.13% heavier than the average weight of Cyclocross bikes.
Cyclo Cross 5 components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When leaving the production line, the Cyclo Cross 5 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida Cyclo Cross 5 has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
