Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CYCLO CROSS CF3
Suspension Fork
CC Carbon disc 15
Drivetrain
Rear Derailleur
Shimano 105 SS
Front Derailleur
Shimano 105 D
Shift Levers
Shimano 105
Cassette
Shimano CS-5800-11 11-28
Crank
Shimano RS500 46-36 (BB86)
Bottom Bracket
BB86/BB92, press-fit
Chain
KMC X11
Wheels
Front Hub
Formula Centerlock-15 / Formula Centerlock-12 11s
Rear Hub
Formula Centerlock-15 / Formula Centerlock-12 11s
Rims
MERIDA comp 22 disc cross
Spokes
Black stainless
Tires
Maxxis Mud Wrestler 33 fold
Brakes
Brakes
Tektro Spyre disc 160
Brake Levers
On Bar Lever additional
Cockpit
Handlebar
MERIDA Road Pro Classic OS
Headset
FSA BB410P/No.55E
Seat
Saddle
MERIDA Sport Pro
Seatpost
MERIDA carbon H SB15 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 53cm | 56cm | 59cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.44 mm | 1.46 mm | 1.48 mm | 1.5 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm | 276 mm | 276 mm |
| Front Center | 579 mm | 575 mm | 589 mm | 598 mm | 614 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 69 mm | 63 mm | 63 mm | 60 mm | 60 mm |
| Stack | 523 mm | 537 mm | 556 mm | 576 mm | 596 mm |
| Reach | 372 mm | 372 mm | 381 mm | 389 mm | 398 mm |
| Top Tube Length | 522 mm | 532 mm | 547 mm | 560 mm | 575 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 100 mm | 111 mm | 131 mm | 150 mm | 171 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 994 mm | 990 mm | 1005 mm | 1014 mm | 1030 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 792 mm | 817 mm | 844 mm | 872 mm | 897 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
CYCLO CROSS 5000 belongs to the Merida Cyclo model. There are 28 bikes that carry this model name. You can easily view all of the Merida Cyclo bikes models from 2016, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Cyclocross bikes average price
Our math shows that the average cost of a dependable Cyclocross bike is 2012$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Cyclocross bikes
The average weight for Cyclocross bikes is 8.79 kg (19.38 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 9.1 kg (20.06 lbs), the CYCLO CROSS 5000 model is slightly heavier than average. In conclusion, the average Cyclocross bike weighs 3.53% less than CYCLO CROSS 5000.
CYCLO CROSS 5000 components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When leaving the production line, the CYCLO CROSS 5000 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The CYCLO CROSS 5000 has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
