Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Fork SunTour NEX -
Groupset Alfine -
Suspension Hardtail -
Motor Bosch mid-drive -
Battery Bosch PowerPack 400Wh -
Drivetrain Internally Geared Hub -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-SPRESSO SPORT
Suspension Fork
SF16-NEX-DS-700C 50 [700C]
Drivetrain
Shift Levers
ALFINE Sl-S7000-8 rapidfire
Cassette
SM-Gear 20T
Crank
Metropolis AL-8/IS
Chain
Z1HX narrow (Z610HX-NPNP)
Wheels
Front Hub
Deore HB-M615 / ALFINE 8s cen NEW
Rear Hub
Deore HB-M615 / ALFINE 8s cen NEW
Rims
MERIDA comp D
Spokes
stainless
Tires
ENERGIZER LIFE
Brakes
Brakes
HD-M315 180 / 160
Brake Levers
attached
Cockpit
Handlebar
HB-RB11
Headset
VP-J203PES
Seat
Saddle
VL-3378
Seatpost
XM Comp D SB15 31.6
Motor & Battery
Motor
Bosch Active Line
Battery
Bosch PowerPack 400Wh
Remote
Bosch Intuvia
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 51cm | 56cm | 61cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.61 mm | 1.6 mm | 1.68 mm |
| Front Center | 626 mm | 636 mm | 651 mm | 667 mm |
| Rake | 45 mm | 45 mm | 44 mm | 46 mm |
| Trail | 73 mm | 73 mm | 70 mm | 65 mm |
| Stack | 619 mm | 619 mm | 640 mm | 681 mm |
| Reach | 375 mm | 385 mm | 399 mm | 406 mm |
| Top Tube Length | 567 mm | 577 mm | 597 mm | 617 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 510 mm | 560 mm | 610 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 140 mm | 140 mm | 160 mm | 200 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1074 mm | 1084 mm | 1099 mm | 1115 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 747 mm | 791 mm | 835 mm | 882 mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
E-SPRESSO SPORT 408 is part of the Merida E E Spresso model. Merida released 11 e-bikes variations of this model so far. You can get a glimpse at all models from 2017, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Hybrid e-bikes average price
According to our math, the average price for a trustworthy Hybrid e-bike is 2480$. However, you could also get a good Hybrid e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
E-SPRESSO SPORT 408 components
Fork
Merida E-SPRESSO SPORT 408 2017 e-bike is equipped with the SunTour NEX fork, and has mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the E-SPRESSO SPORT 408 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
