Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Fork SunTour NCX -
Groupset XT -
Suspension Hardtail -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch PowerPack 500Wh -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-SPRESSO TOUR
Suspension Fork
SF14-NCX-D-PM-DS-RL Air 63 700C CTS
Drivetrain
Rear Derailleur
Shimano XT-11 [GS]
Shift Levers
Shimano XT rapidfire plus 11
Cassette
CS-M8000-11 11-40
Crank
Metropolis AL-8/IS
Chain
x11e EPT
Wheels
Front Hub
Deore XT HB-M8000 / Deore XT FH-M8000
Rear Hub
Deore XT HB-M8000 / Deore XT FH-M8000
Rims
MERIDA comp D
Spokes
INDUSTRY BLACK
Tires
ENERGIZER PLUS
Brakes
Brakes
BR-M447 180 / BR-M447 160
Brake Levers
BL-M445
Cockpit
Handlebar
JD-MTB436AE(ISO4210-M)
Headset
FSA NO.55E / BB-410-SL
Seat
Saddle
MERIDA E23
Seatpost
XM Comp D SB15 31.6
Motor & Battery
Motor
Bosch Performance Line CX
Battery
Bosch PowerPack 500Wh
Remote
Bosch Intuvia
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 54cm |
|---|---|---|---|
| Stack Reach Ratio | 1.64 mm | 1.68 mm | 1.67 mm |
| Front Center | 623 mm | 634 mm | 649 mm |
| Rake | 42 mm | 43 mm | 42 mm |
| Trail | 76 mm | 75 mm | 72 mm |
| Stack | 623 mm | 642 mm | 663 mm |
| Reach | 379 mm | 383 mm | 397 mm |
| Top Tube Length | 571 mm | 581 mm | 601 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 430 mm | 470 mm | 510 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 461 mm | 461 mm | 461 mm |
| Wheelbase | 1075 mm | 1086 mm | 1101 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 643 mm | 635 mm | 633 mm |
| Wheels | 700 | 700 | 700 |
Model Overview
E-SPRESSO TOUR 511 belongs to the Merida E E Spresso model. Merida released 11 e-bikes variations of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Hybrid e-bikes average price
If you want to purchase a solid Hybrid e-bike, it is important to know that the average cost is 2480$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
E-SPRESSO TOUR 511 components
Fork
Merida E-SPRESSO TOUR 511 2017 e-bike is equipped with the SunTour NCX fork, and has mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the E-SPRESSO TOUR 511 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The E-SPRESSO TOUR 511 comes with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
