Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour RAIDON
-
Groupset XT, SLX -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery Shimano E8035, 504Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eBIG.NINE LITE II, material: aluminium, 29" wheelsize, 148x12mm axle standard, intube, max. 504 Wh
Suspension Fork
Suntour RAIDON34 LOR, Air, 100mm suspension travel, Tapered, 51mm fork offset
Drivetrain
Rear Derailleur
Shimano XT RDM8100 Shadow+
Shift Levers
Shimano SLX 12
Cassette
Shimano M7100, 10-51 teeth, 12 speed
Crank
Shimano CRE70-12-B, 36 teeth, Shimano FC-E8000
Bottom Bracket
included
Chain
CN-M7100
Wheels
Front Hub
Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock
Rear Hub
Shimano MT510-B, 148x12mm width rear hub, 36 spoke holes, Centerlock
Rims
MERIDA Comp CC, 20mm inner width, material: aluminium
Spokes
Black stainless
Tires
Maxxis Ikon, 29x2.2", fold
Brakes
Brakes
Shimano MT-500, 2 piston
Cockpit
Handlebar
MERIDA Expert CC, material: aluminium, 720mm width, 10mm rise
Headset
MERIDA 1901
Seat
Saddle
MERIDA EXPERT TK, V-mount
Seatpost
MERIDA EXPERT CC, material: aluminium, 34.9mm diameter, 0mm setback
Motor & Battery
Motor
Shimano E7000, 60Nm
Battery
Shimano E8035, 504Wh
Remote
Shimano SC-E6100
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.5 mm | 1.46 mm | 1.42 mm |
| Bottom Bracket Height | 312 mm | 312 mm | 312 mm | 312 mm |
| Front Center | 685 mm | 702 mm | 723 mm | 744 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 96 mm | 96 mm | 96 mm | 96 mm |
| Stack | 611.5 mm | 621 mm | 630 mm | 639.5 mm |
| Reach | 401.5 mm | 414 mm | 431.5 mm | 449 mm |
| Top Tube Length | 572 mm | 587 mm | 607 mm | 627 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 462 mm | 462 mm | 462 mm | 462 mm |
| Wheelbase | 1140 mm | 1157 mm | 1178 mm | 1199 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm | 62 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
eBIG.NINE 500 EQ belongs to the Merida E Ebignine model. Merida released 51 e-bikes variations of this model so far. Take a sneak peek at all Merida E Ebignine e-bikes models from 2020, by clicking here.
Model range prices
Merida eBIG.NINE 300 SE 2020 is the most economical model, with a starting price of 3223$. Merida eBIG.NINE 400 2020 on the other hand costs 3892$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry e-bikes
If you want to purchase a solid Crosscountry e-bike, it is important to know that the average cost is 2453$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Crosscountry e-bikes average weight
The average weight for Crosscountry e-bikes is 23.21 kg (51.17 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
slightly heavier than average, eBIG.NINE 500 EQ has a weight of 23.33 kg (51.43 lbs). To sum up, it’s 0.52% heavier than the average weight of Crosscountry e-bikes.
Overview of components
Fork
The fork installed on this bike is the SunTour RAIDON model. The travel on this model is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
As for the wheels, Merida eBIG.NINE 500 EQ 2020, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The eBIG.NINE 500 EQ has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
