Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 27.5" / 29" -
Fork Fox Rhythm Float 32 -
Groupset XT Di2, Shimano -
Suspension Hardtail -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano E8010 500Wh -
Drivetrain 1 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
MD
168cm - 180cm
MD
168cm - 180cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eBIG.NINE/SEVEN E8000
Suspension Fork
FOX Rhythm 32 Float Boost
Drivetrain
Rear Derailleur
Shimano XT Di2 RD-M8050
Shift Levers
Shift Switch XT Di2
Cassette
Shimano XT, 11 speed, 11-46 teeth
Crank
Shimano CRE80-B 38
Chain
KMC X11e
Wheels
Rims
XM 1501 Spline ONE 25 boost centerlock wheelset
Tires
Maxxis Forekaster
Brakes
Brakes
Shimano XT hydraulic disc brakes with Ice-tech cooling, 180mm centrelock rotors
Brake Levers
attached
Cockpit
Handlebar
MERIDA Expert Oversize clamp, 10mm rise, 720mm wide
Headset
MERIDA 2333 Neck
Seat
Saddle
MERIDA Expert
Seatpost
MERIDA Expert 30.9mm, 15mm offset
Motor & Battery
Motor
Shimano [E8000]
Battery
Shimano E8010 500Wh
Remote
Shimano SC-E8000
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD | MD | MD | LG | XL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.42 mm | 1.42 mm | 1.58 mm | 1.58 mm | 1.53 mm | 1.5 mm |
| Bottom Bracket Height | 328 mm | 328 mm | 347 mm | 290 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 667 mm | 688 mm | 688 mm | 673 mm | 673 mm | 693 mm | 714 mm |
| Rake | 42 mm | 42 mm | 42 mm | 51 mm | 51 mm | 50 mm | 51 mm |
| Trail | 98 mm | 98 mm | 106 mm | 78 mm | 86 mm | 87 mm | 86 mm |
| Stack | 576 mm | 585 mm | 585 mm | 631 mm | 631 mm | 640 mm | 649 mm |
| Reach | 396 mm | 413 mm | 413 mm | 399 mm | 399 mm | 417 mm | 434 mm |
| Top Tube Length | 567 mm | 587 mm | 587 mm | 587 mm | 587 mm | 607 mm | 627 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 430 mm | 430 mm | 430 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 125 mm | 135 mm | 135 mm | 115 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1101 mm | 1122 mm | 1122 mm | 1120 mm | 1120 mm | 1140 mm | 1161 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 707 mm | 746 mm | 746 mm | 730 mm | 730 mm | 774 mm | 816 mm |
| Wheels | 27" | 27" | 29" | 27" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 168 cm | 168 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 180 cm | 180 cm | 180 cm | 189 cm | 199 cm |
Model Overview
eBIG.NINE/SEVEN 900E is a Merida E Ebignineseven model. Merida launched 5 e-bikes of this model so far. You can easily view all of the Merida E Ebignineseven e-bikes models from 2018, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry e-bikes
According to our math, the average price for a trustworthy Crosscountry e-bike is 2453$. However, even though the average price of a Crosscountry e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
eBIG.NINE/SEVEN 900E components
Fork
Merida eBIG.NINE/SEVEN 900E 2018 e-bike is equipped with the Fox Rhythm Float 32 fork, and has mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The eBIG.NINE/SEVEN 900E 2018 e-bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida eBIG.NINE/SEVEN 900E has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
eBIG.NINE/SEVEN 900E comes in 7 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
