Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Alivio, Shimano -
Suspension Hardtail -
Motor Shimano 250W 85Nm mid-drive -
Battery Shimano EN605, 504Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eBIG.SEVEN LITE, material: aluminium, max. wheelsize 27.5x2.20" without fender max./ 27.5"x2.00" with fender max. wheelsize, 148x12mm axle standard, external
Suspension Fork
Suntour XCM32 DS, Coil, 100mm, Tapered, 47mm fork offset, 27.5x2.2" max wheelsize
Drivetrain
Rear Derailleur
Shimano Alivio M3100, SGS
Shift Levers
Shimano Alivio M3100 9
Cassette
Shimano HG200, 11-36 teeth, 9 speed
Crank
Shimano CRE70-B, 34 teeth
Bottom Bracket
BSA, 73mm, threaded
Chain
KMC e9S
Pedals
VP VPE-537
Wheels
Front Hub
Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock
Rear Hub
Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock
Rims
MERIDA COMP CC, 20mm inner width, material: aluminium
Tires
Front: Maxxis Ikon, 27.5x2.2", Rear: Maxxis Ikon, 27.5x2.2"
Brakes
Brakes
Shimano MT-200, 2 piston
Cockpit
Stem
MERIDA EXPERT CC, 31,8mm diameter, 6° stem angle, 70 mm-S, 80 mm-M
Handlebar
MERIDA EXPERT CC, 720mm width, 10mm rise
Headset
Merida 2341 Neck
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA EXPERT, 30.9mm diameter, 15mm setback
Motor & Battery
Motor
Shimano EP6, 85Nm
Battery
Shimano EN605, 504Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM |
|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.45 mm |
| Bottom Bracket Height | 328 mm | 328 mm |
| Front Center | 666 mm | 667 mm |
| Rake | 42 mm | 42 mm |
| Trail | 98 mm | 98 mm |
| Stack | 567 mm | 577 mm |
| Reach | 399 mm | 397 mm |
| Top Tube Length | 568 mm | 568 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 330 mm | 380 mm |
| Head Tube Angle | 68 ° | 68 ° |
| Head Tube Length | 115 mm | 125 mm |
| Chainstay Length | 453 mm | 436 mm |
| Wheelbase | 1118 mm | 1102 mm |
| Bottom Bracket Drop | 27 mm | 27 mm |
| Standover Height | 671 mm | 708 mm |
| Wheels | 27" | 27" |
Model Overview
eBIG.SEVEN 300 SE (EP6) belongs to the Merida E Ebigseven model. Merida released 18 e-bikes variations of this model so far. Take a sneak peek at all Merida E Ebigseven e-bikes models from 2023, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry e-bikes average price
According to our calculations, the average cost of a Crosscountry e-bike that is reliable is 2453$. However, this doesn’t mean that if you spend less money on a Crosscountry e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
eBIG.SEVEN 300 SE (EP6) components
Fork
Merida eBIG.SEVEN 300 SE (EP6) 2023 e-bike is equipped with the Suntour XCM fork, and has 100mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the eBIG.SEVEN 300 SE (EP6) model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida eBIG.SEVEN 300 SE (EP6) is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
