Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour RAIDON
-
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery Shimano E8010, 504 Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eBIG.SEVEN
Suspension Fork
Suntour Raidon32 LO-R, Air, 100mm suspension travel, Tapered
Drivetrain
Rear Derailleur
Shimano Deore Shadow+
Front Derailleur
no
Shift Levers
no / Shimano Deore
Cassette
Shimano HG500, 11-42 teeth, 10 speed
Crank
Shimano CRE70-B, 34 teeth
Chain
KMC e10 Sport EPT
Wheels
Front Hub
Shimano MT400-B, 110x15mm width, 32 spoke holes, Centerlock / Shimano MT400-B, 148x12mm width, 36 spoke holes, Centerlock
Rear Hub
Shimano MT400-B, 110x15mm width, 32 spoke holes, Centerlock / Shimano MT400-B, 148x12mm width, 36 spoke holes, Centerlock
Rims
MERIDA Comp CC, 20mm inner width,
Spokes
Black stainless
Tires
Continental Double Fighter III, 27.5x2.0", wire
Brakes
Brakes
Shimano MT-200
Brake Levers
attached
Cockpit
Handlebar
MERIDA Expert CC, 720mm width, 10mm rise
Headset
MERIDA 2341 Neck, 2191022388
Seat
Saddle
MERIDA Comfort
Seatpost
MERIDA Expert, 30.9mm diameter, 0mm setback
Motor & Battery
Motor
Shimano E7000, 60Nm
Battery
Shimano E8010, 504 Wh
Remote
Shimano SC-E6100
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.42 mm |
| Bottom Bracket Height | 328 mm | 328 mm |
| Front Center | 667 mm | 688 mm |
| Rake | 42 mm | 42 mm |
| Trail | 98 mm | 98 mm |
| Stack | 576 mm | 585 mm |
| Reach | 396 mm | 413 mm |
| Top Tube Length | 567 mm | 587 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 430 mm |
| Head Tube Angle | 68 ° | 68 ° |
| Head Tube Length | 125 mm | 135 mm |
| Chainstay Length | 435 mm | 435 mm |
| Wheelbase | 1101 mm | 1122 mm |
| Bottom Bracket Drop | 27 mm | 27 mm |
| Standover Height | 707 mm | 746 mm |
| Wheels | 27" | 27" |
Model Overview
eBIG.SEVEN 500 EQ belongs to the Merida E Ebigseven model. 17 e-bikes variations carry this model name so far. You can easily view all of the Merida E Ebigseven e-bikes models from 2019, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry e-bikes average price
If you want an acceptable Crosscountry e-bike you should know that the average price is 2453$. However, this doesn’t mean that if you spend less money on a Crosscountry e-bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
eBIG.SEVEN 500 EQ components
Fork
The SunTour RAIDON is included from the factory. It has a travel distance of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
As for the wheels, Merida eBIG.SEVEN 500 EQ 2019, has a 27.5″ aluminum model. These wheels will provide you with more control over the e-bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
