Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 27.5" -
Travel Front 100mm -
Fork Manitou Machete Comp
-
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano E8010, 504 Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eBIG.SEVEN
Suspension Fork
Manitou Machete Comp, Air, 100mm suspension travel, Tapered
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore Shadow+
Front Derailleur
no
Shift Levers
no / Shimano Deore
Cassette
Shimano HG500, 11-42 teeth, 10 speed
Crank
Shimano CRE80-B, 38 teeth
Chain
KMC X10e
Chain Guide
N/A
Pedals
VP VPE-537
Wheels
Front Hub
Shimano Deore, 110x15mm width, 32 spoke holes, Centerlock / Shimano Deore, 148x12mm width, 36 spoke holes, Centerlock
Rear Hub
Shimano Deore, 110x15mm width, 32 spoke holes, Centerlock / Shimano Deore, 148x12mm width, 36 spoke holes, Centerlock
Rims
MERIDA Comp CC, 20mm inner width,
Spokes
Black stainless
Tires
Maxxis Forekaster, 27.5x2.2", fold
Brakes
Brakes
Shimano MT-500
Brake Levers
attached
Cockpit
Stem
Merida Expert CC, 31.8mm diameter, 6° stem angle
Handlebar
MERIDA Expert CC, 720mm width, 10mm rise
Grips
Merida Expert EC
Headset
MERIDA 2341 Neck, 2191022388
Seat
Saddle
MERIDA Comp CC
Seatpost
MERIDA Expert, 30.9mm diameter, 15mm setback
Motor & Battery
Motor
Shimano E8000, 70Nm
Battery
Shimano E8010, 504 Wh
Remote
Shimano SC-E8000
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.42 mm |
| Bottom Bracket Height | 328 mm | 328 mm |
| Front Center | 667 mm | 688 mm |
| Rake | 42 mm | 42 mm |
| Trail | 98 mm | 98 mm |
| Stack | 576 mm | 585 mm |
| Reach | 396 mm | 413 mm |
| Top Tube Length | 567 mm | 587 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 430 mm |
| Head Tube Angle | 68 ° | 68 ° |
| Head Tube Length | 125 mm | 135 mm |
| Chainstay Length | 435 mm | 435 mm |
| Wheelbase | 1101 mm | 1122 mm |
| Bottom Bracket Drop | 27 mm | 27 mm |
| Standover Height | 707 mm | 746 mm |
| Wheels | 27" | 27" |
| Rider Min Height | 160 cm | 166 cm |
| Rider Max Height | 172 cm | 179 cm |
Model Overview
eBIG.SEVEN 600 completes the Merida E Ebigseven model. There are 17 e-bikes that carry this model name. Take a sneak peek at all Merida E Ebigseven e-bikes models from 2019, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry e-bikes average price
If you want to purchase a solid Crosscountry e-bike, it is important to know that the average cost is 2453$. However, you could also get a good Crosscountry e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Crosscountry e-bikes
On a deeper look, we notice that the average weight of a Crosscountry e-bike is 23.21 kg (51.17 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Merida eBIG.SEVEN 600 it’s weighing 19.03 kg (41.95 lbs). At this weight, is much lighter than average. In other words, this model is 21.97% lighter than the average Crosscountry e-bike.
Overview of components
Fork
This e-bike has the Manitou Machete Comp fork installed. The fork’s travel is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The eBIG.SEVEN 600 2019 e-bike is equipped with 27.5″ aluminum wheels when leaving the factory. These wheels will provide you with more control over the e-bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The eBIG.SEVEN 600 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 2 sizes. They vary from 160 cm – 179 cm (5.25 ft – 5.87 ft). In short, it won’t be difficult to find the right one for you.
