Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour RAIDON
-
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano E8010, 504 Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eBIG.SEVEN
Suspension Fork
Suntour Raidon32 LO-R, Air, 100mm suspension travel, Tapered
Drivetrain
Rear Derailleur
Shimano Deore Shadow+
Front Derailleur
no
Shift Levers
no / Shimano Deore
Cassette
Shimano HG500, 11-42 teeth, 10 speed
Crank
Shimano CRE80-B, 38 teeth
Chain
KMC X10e
Wheels
Front Hub
Shimano Deore, 110x15mm width, 32 spoke holes, Centerlock / Shimano Deore, 148x12mm width, 36 spoke holes, Centerlock
Rear Hub
Shimano Deore, 110x15mm width, 32 spoke holes, Centerlock / Shimano Deore, 148x12mm width, 36 spoke holes, Centerlock
Rims
MERIDA Comp CC, 20mm inner width,
Spokes
Black stainless
Tires
Continental Double Fighter III, 27.5x2.0", wire
Brakes
Brakes
Shimano MT-500
Brake Levers
attached
Cockpit
Handlebar
MERIDA Expert CC, 720mm width, 10mm rise
Headset
MERIDA 2341 Neck, 2191022388
Seat
Saddle
MERIDA Comfort
Seatpost
MERIDA Expert, 30.9mm diameter, 0mm setback
Motor & Battery
Motor
Shimano E8000, 70Nm
Battery
Shimano E8010, 504 Wh
Remote
Shimano SC-E6100
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.42 mm |
| Bottom Bracket Height | 328 mm | 328 mm |
| Front Center | 667 mm | 688 mm |
| Rake | 42 mm | 42 mm |
| Trail | 98 mm | 98 mm |
| Stack | 576 mm | 585 mm |
| Reach | 396 mm | 413 mm |
| Top Tube Length | 567 mm | 587 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 430 mm |
| Head Tube Angle | 68 ° | 68 ° |
| Head Tube Length | 125 mm | 135 mm |
| Chainstay Length | 435 mm | 435 mm |
| Wheelbase | 1101 mm | 1122 mm |
| Bottom Bracket Drop | 27 mm | 27 mm |
| Standover Height | 707 mm | 746 mm |
| Wheels | 27" | 27" |
Model Overview
eBIG.SEVEN 600 EQ completes the Merida E Ebigseven model. 17 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2019, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry e-bikes
If you want to purchase a solid Crosscountry e-bike, it is important to know that the average cost is 2453$. However, this doesn’t mean that if you spend less money on a Crosscountry e-bike, you couldn’t get a decent one. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
The fork installed on this bike is the SunTour RAIDON model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
As for the wheels, Merida eBIG.SEVEN 600 EQ 2019, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida eBIG.SEVEN 600 EQ has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
