Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour RAIDON
-
Groupset XT, SLX -
Suspension Hardtail -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano E8010, 504 Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eBIG.SEVEN
Suspension Fork
Suntour Raidon32 LO-R, Air, 100mm suspension travel, Tapered
Drivetrain
Rear Derailleur
Shimano XT M8000 Shadow+
Front Derailleur
no
Shift Levers
no / Shimano SLX 11
Cassette
Shimano M7000, 11-46 teeth, 11 speed
Crank
Shimano CRE80-B, 38 teeth
Chain
KMC e11 Sport EPT
Wheels
Front Hub
Shimano Deore, 110x15mm width, 32 spoke holes, Centerlock / Shimano Deore, 148x12mm width, 36 spoke holes, Centerlock
Rear Hub
Shimano Deore, 110x15mm width, 32 spoke holes, Centerlock / Shimano Deore, 148x12mm width, 36 spoke holes, Centerlock
Rims
MERIDA Comp CC, 20mm inner width,
Spokes
Black stainless
Tires
Continental Double Fighter III, 27.5x2.0", wire
Brakes
Brakes
Shimano SLX
Brake Levers
attached
Cockpit
Handlebar
MERIDA Expert CC, 720mm width, 10mm rise
Headset
MERIDA 2341 Neck, 2191022388
Seat
Saddle
MERIDA Comfort
Seatpost
MERIDA Expert, 30.0mm diameter, 0mm setback
Motor & Battery
Motor
Shimano E8000, 70Nm
Battery
Shimano E8010, 504 Wh
Remote
Shimano SC-E6100
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.42 mm |
| Bottom Bracket Height | 328 mm | 328 mm |
| Front Center | 667 mm | 688 mm |
| Rake | 42 mm | 42 mm |
| Trail | 98 mm | 98 mm |
| Stack | 576 mm | 585 mm |
| Reach | 396 mm | 413 mm |
| Top Tube Length | 567 mm | 587 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 430 mm |
| Head Tube Angle | 68 ° | 68 ° |
| Head Tube Length | 125 mm | 135 mm |
| Chainstay Length | 435 mm | 435 mm |
| Wheelbase | 1101 mm | 1122 mm |
| Bottom Bracket Drop | 27 mm | 27 mm |
| Standover Height | 707 mm | 746 mm |
| Wheels | 27" | 27" |
Model Overview
eBIG.SEVEN 800 EQ is a Merida E Ebigseven model. Merida launched 17 e-bikes of this model so far. You can easily view all of the Merida E Ebigseven e-bikes models from 2019, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry e-bikes average price
Our math shows that the average cost of a dependable Crosscountry e-bike is 2453$. However, this doesn’t mean that if you spend less money on a Crosscountry e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
eBIG.SEVEN 800 EQ components
Fork
The SunTour RAIDON is included from the factory. It has a travel distance of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
As for the wheels, Merida eBIG.SEVEN 800 EQ 2019, has a 27.5″ aluminum model. These wheels will provide you with more control over the e-bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The eBIG.SEVEN 800 EQ comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
