Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 27.5" -
Travel Front 100mm -
Fork Fox Rhythm Float 32
-
Groupset XT, Shimano -
Suspension Hardtail -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano E8010, 504 Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eBIG.SEVEN
Suspension Fork
Fox Rhythm 32 Float, Air, 100mm suspension travel, Tapered, Remote lockout
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano XT
Front Derailleur
no
Shift Levers
no / Shimano XT 11
Cassette
Shimano M7000, 11-46 teeth, 11 speed
Crank
Shimano CRE80-B, 38 teeth
Chain
KMC X11e
Chain Guide
N/A
Pedals
VP VPE-537
Wheels
Front Hub
DT Swiss Spline M1700 wheelset, Centerlock, 110x15mm front, 148x12mm rear
Rear Hub
DT Swiss Spline M1700 wheelset, Centerlock, 110x15mm front, 148x12mm rear
Rims
DT Swiss Spline M1700, 110x15mm width front hub, 148x12mm width rear hub, 35mm inner width, Centerlock
Spokes
attached
Tires
Maxxis Forekaster, 27.5x2.2", fold
Brakes
Brakes
Shimano XT fin
Brake Levers
attached
Cockpit
Stem
Merida Expert CC, 31.8mm diameter, 6° stem angle
Handlebar
MERIDA Expert CC, 720mm width, 10mm rise
Grips
Merida Expert EC
Headset
MERIDA M2333 neck, 2191025648
Seat
Saddle
MERIDA Expert CC
Seatpost
MERIDA Expert, 30.9mm diameter, 15mm setback
Motor & Battery
Motor
Shimano E8000, 70Nm
Battery
Shimano E8010, 504 Wh
Remote
Shimano SC-E8000
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.42 mm |
| Bottom Bracket Height | 328 mm | 328 mm |
| Front Center | 667 mm | 688 mm |
| Rake | 42 mm | 42 mm |
| Trail | 98 mm | 98 mm |
| Stack | 576 mm | 585 mm |
| Reach | 396 mm | 413 mm |
| Top Tube Length | 567 mm | 587 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 430 mm |
| Head Tube Angle | 68 ° | 68 ° |
| Head Tube Length | 125 mm | 135 mm |
| Chainstay Length | 435 mm | 435 mm |
| Wheelbase | 1101 mm | 1122 mm |
| Bottom Bracket Drop | 27 mm | 27 mm |
| Standover Height | 707 mm | 746 mm |
| Wheels | 27" | 27" |
| Rider Min Height | 160 cm | 166 cm |
| Rider Max Height | 172 cm | 179 cm |
Model Overview
eBIG.SEVEN 900 completes the Merida E Ebigseven model. 17 e-bikes variations carry this model name so far. Check out the entire range from 2019 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry e-bikes average price
Our math shows that the average cost of a dependable Crosscountry e-bike is 2453$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Crosscountry e-bikes average weight
If we make a quick analysis of the average weight of a Crosscountry e-bike, we get 23.21 kg (51.17 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Merida eBIG.SEVEN 900 it’s weighing 18.77 kg (41.38 lbs). At this weight, is much lighter than average. In conclusion, the average Crosscountry e-bike weighs 23.65% more than eBIG.SEVEN 900.
Overview of components
Fork
The Fox Rhythm Float 32 is included from the factory. It has a travel distance of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When it comes to wheels, the eBIG.SEVEN 900 e-bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Merida eBIG.SEVEN 900 e-bike has 2 sizes, in the range of 160 cm – 179 cm (5.25 ft – 5.87 ft). In short, you can easily find one that suits you.
