Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 27.5" -
Fork RockShox Pike RCT3 -
Groupset XT, XT Di2 -
Suspension Hardtail -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano E8010 500Wh -
Drivetrain 1 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eBIG.TRAIL (STePS)
Suspension Fork
Rock Shox PIKE RCT3 27.5"+ BOOST
Drivetrain
Rear Derailleur
Shimano XT GS Shadow+
Shift Levers
Shift Switch XT Di2
Cassette
Shimano XT 11-46 11s
Crank
Shimano CRE80-B 34, SM-CDE 80 Chainguide
Bottom Bracket
STEPS, press-fit
Chain
KMC X11EL
Wheels
Front Hub
attached
Rear Hub
attached
Rims
DT Swiss XM1501 Spline one 40 boost TC
Spokes
attached
Tires
Maxxis Rekon 27.5+ 2.8 fold
Brakes
Brakes
Shimano XT fin ice
Brake Levers
attached
Cockpit
Handlebar
MERIDA EXPERT 35 760
Seat
Saddle
MERIDA Expert
Seatpost
Rock Shox Reverb Stealth 30.9
Motor & Battery
Motor
Shimano DU-E8000
Battery
Shimano E8010 500Wh
Remote
Shimano Cyclo display SC-E8000
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.573 mm | 1.522 mm | 1.474 mm | 1.43 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm | 295 mm |
| Front Center | 702 mm | 726 mm | 749 mm | 773 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 92 mm | 92 mm | 92 mm | 92 mm |
| Stack | 637 mm | 647 mm | 656 mm | 665 mm |
| Reach | 405 mm | 425 mm | 445 mm | 465 mm |
| Top Tube Length | 582 mm | 604 mm | 627 mm | 649 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 490 mm | 540 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1130 mm | 1154 mm | 1177 mm | 1201 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 650 | 682 mm | 705 mm | 736 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
eBIG.TRAIL 900E is part of the Merida E Ebigtrail model. Merida released 10 e-bikes variations of this model so far. Take a sneak peek at all Merida E Ebigtrail e-bikes models from 2017, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry e-bikes average price
Our math shows that the average cost of a dependable Crosscountry e-bike is 2453$. However, this doesn’t mean that if you spend less money on a Crosscountry e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
eBIG.TRAIL 900E components
Fork
The RockShox Pike RCT3 is included from the factory. It has a travel distance of mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the eBIG.TRAIL 900E e-bike is equipped with the 27.5″ aluminum model. These wheels will provide you with more control over the e-bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida eBIG.TRAIL 900E has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Merida eBIG.TRAIL 900E includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
