Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 27.5" -
Travel Front 130mm -
Fork RockShox Pike RCT3
-
Groupset XT Di2, Shimano -
Suspension Hardtail -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano E8010 500Wh -
Drivetrain 1 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eBIG.TRAIL
Suspension Fork
Rock Shox Pike RCT3, 130mm travel, B Boost
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano XT Di2 RD-M8050
Front Derailleur
N/A
Shift Levers
Shift Switch XT Di2
Cassette
Shimano XT, 11 speed, 11-46 teeth
Crank
Shimano CRE80-B 34, SM-CDE 80 Chainguide
Chain
KMC X11e
Chain Guide
Shimano SM-CDE 80
Pedals
VP Components, VPE-537
Wheels
Front Hub
DT Swiss HX 1501 Spline One, Boost
Rear Hub
DT Swiss HX 1501 Spline One, Boost
Rims
DT Swiss HX1501 Spline one 35 boost wheelset
Spokes
DT Swiss
Tires
Maxxis Rekon 27.5"+ 2.8" folding
Brakes
Brakes
Shimano XT hydraulic disc brakes with Ice-tech cooling, 203mm 6 bolt rotors
Brake Levers
attached
Cockpit
Stem
Merida Expert SS, 45mm length
Handlebar
MERIDA EXPERT II 780mm, rise: 20 mm, dia: 35mm, 6°
Headset
FSA NO.55EP neck
Seat
Saddle
MERIDA EXPERT
Seatpost
Rock Shox Reverb Stealth 30.9mm
Motor & Battery
Motor
Shimano [E8000]
Battery
Shimano E8010 500Wh
Remote
Shimano SC-E8000
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.573 mm | 1.522 mm | 1.474 mm | 1.43 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm | 295 mm |
| Front Center | 702 mm | 726 mm | 749 mm | 773 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 92 mm | 92 mm | 92 mm | 92 mm |
| Stack | 637 mm | 647 mm | 656 mm | 665 mm |
| Reach | 405 mm | 425 mm | 445 mm | 465 mm |
| Top Tube Length | 582 mm | 604 mm | 627 mm | 649 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 490 mm | 540 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1130 mm | 1154 mm | 1177 mm | 1201 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 650 | 682 mm | 705 mm | 736 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
eBIG.TRAIL 900E is part of the Merida E Ebigtrail model. 10 e-bikes variations carry this model name so far. Check out the entire range from 2018 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail e-bikes
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Trail e-bikes average weight
If we make a quick analysis of the average weight of a Trail e-bike, we get 23.7 kg (52.25 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
eBIG.TRAIL 900E weighs 20.5 kg (45.19 lbs) and is much lighter than the average. To sum up, it’s 15.61% lighter than the average weight of Trail e-bikes.
Overview of components
Fork
This e-bike has the RockShox Pike RCT3 fork installed. The fork’s travel is 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
As for the wheels, Merida eBIG.TRAIL 900E 2018, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The eBIG.TRAIL 900E comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Merida eBIG.TRAIL 900E comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
