Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 133mm -
Fork Fox Rhythm Float 34
-
Groupset XT, Shimano -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Shimano E8036 630Wh / Shimano E8035 504Wh for S only -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eONE-FORTY CFA II, material: carbon, 133mm suspension travel, 27.5x2.8" max. wheelsize, 148x12mm axle standard, intube, max. 630 Wh
Suspension Fork
FOX Rhythm 34 Float eMTB+, Air, 140mm suspension travel, Tapered, 51mm fork offset, 29x2.5" max wheelsize
Rear Shock
FOX Performance Float DPS, lockout
Drivetrain
Rear Derailleur
Shimano XT RDM8130 Shadow+ 11
Shift Levers
Shimano SL -MT500-IL
Cassette
Shimano LG600, 11-50 teeth, 11 speed
Crank
Shimano CRE80-B, 34 teeth
Bottom Bracket
BSA, 73mm, threaded
Chain
CNLG500
Wheels
Front Hub
Shimano XT, 110x15mm width front hub, 32 spoke holes, Centerlock
Rear Hub
Shimano XT, 148x12mm width rear hub, 36 spoke holes, Centerlock
Rims
MERIDA EXPERT TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Spokes
Black stainless
Tires
Continental Trail King, 29x2.4 ", fold, BlackChili, ProTection Apex, TR
Brakes
Brakes
Shimano SLX, 4 piston
Disk Rotors
Shimano RT64 / Shimano RTEM600, 203 mm
Cockpit
Handlebar
MERIDA EXPERT eTR, 780mm width, 20mm rise
Headset
MERIDA 8152
Seat
Saddle
MERIDA EXPERT CC, V-mount
Seatpost
MERIDA EXPERT TR, 30.9mm diameter, 0mm setback, S 100mm travel seatpost - S/M 125mm travel seatpost - L 150mm travel seatpost - XL/XXL 170mm travel seatpost
Motor & Battery
Motor
Shimano EP8, 85Nm
Battery
Shimano E8036 630Wh / Shimano E8035 504Wh for S only
Remote
Shimano SC-E7000
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.45 mm | 1.4 mm | 1.37 mm | 1.34 mm |
| Bottom Bracket Height | 331 mm | 331 mm | 331 mm | 331 mm | 331 mm |
| Front Center | 722 mm | 744 mm | 766 mm | 792 mm | 818 mm |
| Rake | 47 mm | 47 mm | 47 mm | 48 mm | 48 mm |
| Trail | 103 mm | 103 mm | 103 mm | 102 mm | 102 mm |
| Stack | 627 mm | 631.5 mm | 636 mm | 649.5 mm | 663 mm |
| Reach | 415 mm | 434.5 mm | 454.5 mm | 474.5 mm | 494.5 mm |
| Top Tube Length | 566 mm | 587 mm | 608 mm | 631 mm | 655 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 405 mm | 420 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 110 mm | 115 mm | 120 mm | 135 mm | 150 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1165 mm | 1187 mm | 1209 mm | 1235 mm | 1261 mm |
| Bottom Bracket Drop | 24 mm | 24 mm | 24 mm | 24 mm | 24 mm |
| Standover Height | 741 mm | 736 mm | 732 mm | 739 mm | 753 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
Model Overview
eONE-FORTY 8000 is part of the Merida E Eone Forty model. Merida launched 32 e-bikes of this model so far. Take a sneak peek at all Merida E Eone Forty e-bikes models from 2022, by clicking here.
Model range prices
The most economical model, the Merida eONE-FORTY 400 2022 has a starting price of 5048$. Merida eONE-FORTY 700 2022 on the other hand is the most expensive at 6812$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail e-bikes average price
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The Fox Rhythm Float 34 is included from the factory. It has a travel distance of 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The eONE-FORTY 8000 has a rear shock with a travel of 133mm. The model FOX Performance Float DPS is the one installed in this e-bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When leaving the production line, the eONE-FORTY 8000 model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida eONE-FORTY 8000 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
