Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 160mm -
Fork Fox Factory Float 36
-
Groupset XT Di2, Shimano -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano E8010 with Abus key lock -
Drivetrain 1 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX 36 Factory E-bike, Air, 110x15mm
Rear Shock
FOX Factory Float X2, trunnion mount
Drivetrain
Rear Derailleur
Shimano XT Di2
Front Derailleur
N/A
Shift Levers
Shimano XT Di2
Cassette
Shimano M8000, 11-46 tooth, 11-speed
Crank
Shimano E8050, hollow, 170mm
Chain
KMC X11e
Chain Guide
N/A
Pedals
VP VPE-537
Wheels
Front Hub
DT Swiss Spline HX1501 wheelset, Centerlock, 110x15mm front, 148x12mm rear
Rear Hub
DT Swiss Spline HX1501 wheelset, Centerlock, 110x15mm front, 148x12mm rear
Rims
DT Swiss Spline HX1501 wheelset, 35mm inner width
Spokes
DT Swiss Spline HX1501 wheelset
Tires
Maxxis DHR II, 27.5 x 2.8", folding, 3C, EXO, TR
Brakes
Brakes
Shimano Saint with RT86 rotors (203mm front and rear)
Brake Levers
Shimano Saint
Cockpit
Stem
Merida Expert eTR, 35mm diameter, 0° stem angle
Handlebar
Merida Expert eTR, 20mm rise, 780mm width
Grips
Merida Expert EC
Headset
FSA No. 57/55E Neck
Seat
Saddle
Merida Expert CC
Seatpost
RockShox Reverb, 100mm travel (S), 150mm travel (M, L, XL)
Motor & Battery
Motor
Shimano Steps E8000, max output 70Nm (250W)
Battery
Shimano E8010 with Abus key lock
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.43 mm | 1.41 mm | 1.39 mm |
| Bottom Bracket Height | 328 mm | 328 mm | 328 mm | 328 mm |
| Front Center | 736 mm | 764 mm | 792 mm | 820 mm |
| Rake | 58 mm | 58 mm | 58 mm | 58 mm |
| Trail | 91 mm | 91 mm | 91 mm | 91 mm |
| Stack | 601 mm | 619 mm | 637 mm | 656 mm |
| Reach | 413 mm | 433 mm | 453 mm | 473 mm |
| Top Tube Length | 576 mm | 601 mm | 627 mm | 651 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 410 mm | 430 mm | 470 mm | 510 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1167 mm | 1195 mm | 1223 mm | 1251 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm | 27 mm |
| Standover Height | 717 mm | 720 mm | 750 mm | 782 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
eOne-Sixty 900-E completes the Merida E Eone Sixty model. There are 43 e-bikes that carry this model name. You can easily view all of the Merida E Eone Sixty e-bikes models from 2019, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro e-bikes
If you want to purchase a solid Enduro e-bike, it is important to know that the average cost is 4785$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Enduro e-bikes average weight
The average weight for Enduro e-bikes is 23.42 kg (51.63 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 21.82 kg (48.1 lbs), Merida e-bike is a bit lighter than average. To sum up, it’s 7.33% lighter than the average weight of Enduro e-bikes.
eOne-Sixty 900-E components
Fork
This e-bike has the Fox Factory Float 36 fork installed. The fork’s travel is 160mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the FOX Factory Float X2 rear shock model, which has a travel of 160mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The wheels on eOne-Sixty 900-E are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
eOne-Sixty 900-E comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Merida eOne-Sixty 900-E comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
