Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 27.5" -
Fork RockShox Yari RC -
Groupset Deore, Shimano -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano E8010 500Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eONE-TWENTY (STePS)
Suspension Fork
RockShox FS YARI RC 27.5"+ BOOST
Rear Shock
Rock Shox Super Deluxe R
Drivetrain
Rear Derailleur
Shimano Deore Shadow+
Shift Levers
Shimano Deore
Cassette
Shimano CS-HG50-10 11-36
Crank
Shimano CRE80-B 34, SM-CDE 80 Chainguide
Bottom Bracket
STEPS, press-fit
Chain
KMC X10
Wheels
Front Hub
Shimano Deore boost cen
Rear Hub
Shimano Deore boost cen
Rims
MERIDA Expert TP
Spokes
Black stainless
Tires
Maxxis Rekon 27.5+ 2.8 fold / Maxxis DHR 2 27.5+ 2.8 fold
Brakes
Brakes
Shimano M506
Brake Levers
attached
Cockpit
Handlebar
MERIDA EXPERT 35 760
Seat
Saddle
MERIDA Sport 5
Seatpost
MERIDA EXPERT Dropper 30.9
Motor & Battery
Motor
Shimano DU-E8000
Battery
Shimano E8010 500Wh
Remote
Shimano Cyclo display SC-E8000
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.423 mm | 1.38 mm | 1.341 mm |
| Bottom Bracket Height | 328 mm | 328 mm | 328 mm | 328 mm |
| Front Center | 717 mm | 736 mm | 760 mm | 783 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 92 mm | 92 mm | 92 mm | 92 mm |
| Stack | 609 mm | 619 mm | 628 mm | 637 mm |
| Reach | 420 mm | 435 mm | 455 mm | 475 mm |
| Top Tube Length | 583 mm | 601 mm | 623 mm | 646 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 440 mm | 490 mm | 540 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1155 mm | 1174 mm | 1198 mm | 1221 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm | 27 mm |
| Standover Height | 698 mm | 730 mm | 751 mm | 783 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
eONE-TWENTY 500 is a Merida E Eone Twenty model. There are 15 e-bikes that carry this model name. Take a sneak peek at all Merida E Eone Twenty e-bikes models from 2017, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail e-bikes
According to our calculations, the average cost of a Trail e-bike that is reliable is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
eONE-TWENTY 500 components
Fork
Merida eONE-TWENTY 500 2017 e-bike is equipped with the RockShox Yari RC fork, and has mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The wheels on eONE-TWENTY 500 are the 27.5″ aluminum type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The eONE-TWENTY 500 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
