Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Travel Front 63mm -
Fork SunTour NCX
-
Groupset XT, Shimano -
Suspension Hardtail -
Motor Shimano mid-drive -
Battery Shimano E6001 500Wh -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eSPRESSO CITY (STePS)
Suspension Fork
Suntour NCX-D-DS-RL Air 63 700C CTS
Drivetrain
Rear Derailleur
Shimano XT GS Shadow+
Shift Levers
Shimano XT 11
Cassette
Shimano Gear 21
Crank
Shimano 38 DCG
Bottom Bracket
STEPS, press-fit
Chain
KMC X10
Wheels
Front Hub
Shimano XT cen
Rear Hub
Shimano XT cen
Rims
MERIDA 7 comp CC
Spokes
Black stainless
Tires
Continental Tour Ride 42 Ref.
Brakes
Brakes
Shimano M506
Brake Levers
attached
Cockpit
Handlebar
JD-TR25A 640 R35
Seat
Saddle
MERIDA COMFORT
Seatpost
Suspension One D 27.2
Motor & Battery
Motor
Shimano [E6001]
Battery
Shimano E6001 500Wh
Remote
Shimano Cyclo display SC-E6010
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 51cm | 56cm | 61cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.66 mm | 1.62 mm | 1.61 mm | 1.6 mm |
| Front Center | 667 mm | 676 mm | 698 mm | 719 mm |
| Rake | 46 mm | 44 mm | 45 mm | 45 mm |
| Trail | 81 mm | 84 mm | 82 mm | 82 mm |
| Stack | 649 mm | 650 | 668 mm | 687 mm |
| Reach | 391 mm | 401 mm | 416 mm | 430 mm |
| Top Tube Length | 591 mm | 601 mm | 621 mm | 641 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 430 mm | 480 mm | 530 mm | 580 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 180 mm | 180 mm | 200 mm | 220 mm |
| Chainstay Length | 461 mm | 461 mm | 461 mm | 461 mm |
| Wheelbase | 1120 mm | 1129 mm | 1151 mm | 1172 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheels | 700 | 700 | 700 | 700 |
About this model
eSPRESSO CITY 900 EQ is part of the Merida E Espresso model. 185 e-bikes variations carry this model name so far. Check out the entire range from 2017 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid e-bikes average price
According to our math, the average price for a trustworthy Hybrid e-bike is 2480$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
eSPRESSO CITY 900 EQ components
Fork
Merida eSPRESSO CITY 900 EQ 2017 e-bike is equipped with the SunTour NCX fork, and has 63mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the eSPRESSO CITY 900 EQ model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida eSPRESSO CITY 900 EQ is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
