Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCM HLO
-
Groupset SLX, Shimano -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Juliet Comp 27-Single
Suspension Fork
SR Suntour 27 XCM HLO 100
Drivetrain
Rear Derailleur
Shimano SLX-9
Front Derailleur
Shimano M390
Shift Levers
Shimano Acera-X Rapidfire
Cassette
Shimano CS-HG20-9 11-34
Crank
Shimano M430 Octa 44-32-22 CG
Bottom Bracket
Shimano Octalink
Chain
KMC Z99 9s
Wheels
Front Hub
Alloy Disc QR / Shimano M475 Disc
Rear Hub
Alloy Disc QR / Shimano M475 Disc
Rims
MERIDA Big.Seven Comp D
Spokes
black+white stainless
Tires
MERIDA Race 27.5 2.1
Brakes
Brakes
Tektro HDC Hydraulic Disc 180 mm / Tektro HDC Hydraulic Disc 160 mm
Brake Levers
attached
Cockpit
Handlebar
MERIDA Comp OS 640 R25
Headset
Conoid semi Neck
Seat
Saddle
Juliet Sport
Seatpost
Merida Comp SB12 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13.5" | 15" | 17" | 18.5" | 20" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.55 mm | 1.54 mm | 1.53 mm | 1.53 mm |
| Bottom Bracket Height | 292 mm | 292 mm | 292 mm | 292 mm | 292 mm |
| Stack | 594 mm | 599 mm | 606 mm | 615 mm | 625 mm |
| Reach | 378 mm | 386 mm | 394 mm | 401 mm | 408 mm |
| Top Tube Length | 544 mm | 554 mm | 569 mm | 579 mm | 589 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 343 mm | 381 mm | 432 mm | 470 mm | 508 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 95 mm | 100 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
About this model
Juliet 300-B belongs to the Merida Juliet model. Merida released 74 bikes variations of this model so far. Check out the entire range from 2014 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Crosscountry bikes
Crosscountry bikes weigh an average of 12.4 kg (27.34 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Merida Juliet 300-B it’s weighing 13.6 kg (29.98 lbs). At this weight, is a bit heavier than average. To sum up, it’s 9.68% heavier than the average weight of Crosscountry bikes.
Juliet 300-B components
Fork
Merida Juliet 300-B 2014 bike is equipped with the SunTour XCM HLO fork, and has 100mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When leaving the production line, the Juliet 300-B model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida Juliet 300-B has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
