Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 26" -
Fork SunTour XCT -
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
JULIET SPEED 6.
Suspension Fork
SR 26 XCT-HLO 100
Drivetrain
Rear Derailleur
Shimano Acera-X
Front Derailleur
Shimano M190
Shift Levers
Shimano EZ fire 3 / Shimano EZ fire 8
Cassette
Sunrace CS8 11-32
Crank
Shimano M131 42-34-24 CG
Bottom Bracket
Cartridge Bearing
Chain
Sunrace 8S
Wheels
Front Hub
Alloy Disc / Alloy Disc cassette
Rear Hub
Alloy Disc / Alloy Disc cassette
Rims
MERIDA Juliet D
Tires
MERIDA 26 1.95
Brakes
Brakes
Promax MTD Mechanical 160
Brake Levers
attached
Cockpit
Handlebar
MERIDA Speed R30 620
Headset
Conoid steel
Seat
Saddle
Juliet Sport
Seatpost
MERIDA speed 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13.5" | 15" | 17" | 18.5" | 20" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.55 mm | 1.58 mm | 1.57 mm | 1.57 mm |
| Bottom Bracket Height | 288 mm | 288 mm | 288 mm | 288 mm | 288 mm |
| Front Center | 600 mm | 600 mm | 600 mm | 602 mm | 608 mm |
| Rake | 36 mm | 26 mm | 26 mm | 18 mm | 14 mm |
| Trail | 87 mm | 97 mm | 94 mm | 102 mm | 107 mm |
| Stack | 567 mm | 576 mm | 588 mm | 597 mm | 607 mm |
| Reach | 365 mm | 372 mm | 373 mm | 380 mm | 387 mm |
| Top Tube Length | 534 mm | 544 mm | 554 mm | 564 mm | 574 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 343 mm | 381 mm | 432 mm | 470 mm | 508 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 115 mm | 125 mm | 135 mm | 145 mm | 155 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1013 mm | 1013 mm | 1013 mm | 1015 mm | 1021 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 594 mm | 594 mm | 654 mm | 693 mm | 739 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
Model Overview
Juliet 6. 20-MD belongs to the Merida Juliet model. Merida launched 74 bikes of this model so far. You can get a glimpse at all models from 2015, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
Merida Juliet 6. 20-MD 2015 bike is equipped with the SunTour XCT fork, and has mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When leaving the production line, the Juliet 6. 20-MD model has 26″ aluminum wheels. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida Juliet 6. 20-MD is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
