Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 26" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Acera, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
JULIET SPEED 6.
Suspension Fork
Suntour XCT HLO, Coil, 100mm suspension travel, Lockout
Drivetrain
Rear Derailleur
Shimano RD-M360
Front Derailleur
Shimano FD-TY700
Shift Levers
Shimano ST-EF500
Cassette
Sunrace CSM668, 11-32 teeth, 8 speed
Crank
Shimano TY301, 42-34-24 teeth
Chain
KMC M700
Wheels
Front Hub
Shimano TX505, 100x9mm width, 32 spoke holes, Centerlock / Shimano TX505, 135x9mm width, 32 spoke holes, Centerlock
Rear Hub
Shimano TX505, 100x9mm width, 32 spoke holes, Centerlock / Shimano TX505, 135x9mm width, 32 spoke holes, Centerlock
Rims
MERIDA CC, 17mm inner width,
Spokes
Black steel
Tires
MERIDA K1080, 26x1.95", wire
Brakes
Brakes
Promax MTD-3.0 disc
Brake Levers
Shimano ST-EF500
Cockpit
Handlebar
MERIDA CC, 640mm width, 25mm rise
Headset
FSA NO.10P Neck15
Seat
Saddle
MERIDA Juliet Sport
Seatpost
MERIDA CC, 27.2mm diameter, 15mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.64 mm | 1.64 mm | 1.66 mm |
| Bottom Bracket Height | 288 mm | 288 mm | 288 mm |
| Front Center | 609 mm | 619 mm | 619 mm |
| Rake | 38 mm | 38 mm | 38 mm |
| Trail | 88 mm | 88 mm | 84 mm |
| Stack | 588 mm | 598 mm | 609 mm |
| Reach | 358 mm | 365 mm | 366 mm |
| Top Tube Length | 534 mm | 544 mm | 554 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 343 mm | 381 mm | 432 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° |
| Head Tube Length | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1022 mm | 1032 mm | 1032 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm |
| Standover Height | 583 mm | 615 mm | 668 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
About this model
JULIET 6. 20-MD completes the Merida Juliet model. There are 74 bikes that carry this model name. You can easily view all of the Merida Juliet bikes models from 2019, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Crosscountry bikes average weight
On a deeper look, we notice that the average weight of a Crosscountry bike is 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 14.28 kg (31.48 lbs), the JULIET 6. 20-MD model is much heavier than average. In short, the average Crosscountry bike weight is 15.16% lower than this one.
JULIET 6. 20-MD components
Fork
The JULIET 6. 20-MD comes factory-installed with the SunTour XCT fork. This has a travel range of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on JULIET 6. 20-MD are the 26″ aluminum type. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The JULIET 6. 20-MD comes with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 151 cm – 179 cm (4.95 ft – 5.87 ft). In conclusion, you won’t have a problem finding one that suits you.
