Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 26" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Altus, Suntour SR -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
JULIET SPEED 6.
Suspension Fork
Suntour SR 26 XCT-HLO 100
Drivetrain
Rear Derailleur
Shimano Altus 9
Front Derailleur
Shimano Altus
Shift Levers
Shimano Altus rapidfire
Cassette
Sunrace CS-9S 11-32
Crank
SR XCM 44-32-22 CG (BSA)
Bottom Bracket
BSA, 73mm, threaded
Chain
KMC X9
Wheels
Front Hub
Alloy Disc / Alloy Disc cassette
Rear Hub
Alloy Disc / Alloy Disc cassette
Rims
MERIDA Juliet D
Spokes
stainless silver+white stainless
Tires
MERIDA 26 1.95
Brakes
Brakes
Tektro Auriga WS hydraulic 160
Cockpit
Handlebar
MERIDA Speed R30 620
Headset
FSA No.10
Seat
Saddle
Juliet Sport
Seatpost
MERIDA speed 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13.5" | 15" | 17" | 18.5" | 20" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.64 mm | 1.66 mm | 1.66 mm | 1.65 mm |
| Bottom Bracket Height | 288 mm | 288 mm | 288 mm | 288 mm | 288 mm |
| Front Center | 609 mm | 619 mm | 619 mm | 629 mm | 640 mm |
| Rake | 39 mm | 39 mm | 38 mm | 38 mm | 44 mm |
| Trail | 87 mm | 87 mm | 84 mm | 84 mm | 75 mm |
| Stack | 588 mm | 598 mm | 609 mm | 619 mm | 628 mm |
| Reach | 357 mm | 364 mm | 366 mm | 373 mm | 380 mm |
| Top Tube Length | 534 mm | 544 mm | 554 mm | 564 mm | 574 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 343 mm | 381 mm | 432 mm | 470 mm | 508 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° | 70 ° | 70.5 ° |
| Head Tube Length | 115 mm | 125 mm | 135 mm | 145 mm | 155 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1022 mm | 1032 mm | 1032 mm | 1042 mm | 1053 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 638 mm | 723 mm | 753 mm | 782 mm | mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
Model Overview
JULIET 6. 40-D belongs to the Merida Juliet model. Merida released 74 bikes variations of this model so far. Check out the entire range from 2016 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Crosscountry bikes
On a deeper look, we notice that the average weight of a Crosscountry bike is 12.4 kg (27.34 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Merida JULIET 6. 40-D it’s weighing 14.5 kg (31.97 lbs). At this weight, is much heavier than average. To sum up, it’s 16.94% heavier than the average weight of Crosscountry bikes.
JULIET 6. 40-D components
Fork
The fork installed on this bike is the SunTour XCT model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The wheels on JULIET 6. 40-D are the 26″ aluminum type. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
