Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Fork SunTour XCR Air -
Groupset Deore, Alivio -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
JULIET TFS
Suspension Fork
SR 27 XCR air LO 100
Drivetrain
Rear Derailleur
Shimano Deore-9
Front Derailleur
Shimano Alivio
Shift Levers
Shimano Alivio rapidfire
Cassette
Shimano CS-HG200-9 11-34
Crank
Shimano M4000 octa 40-30-22 CG
Bottom Bracket
Shimano octalink
Chain
KMC M99
Wheels
Front Hub
Formula Disc / Formula Disc cassette
Rear Hub
Formula Disc / Formula Disc cassette
Rims
MERIDA Big 7 comp D
Tires
MERIDA RACE 27 2.1
Brakes
Brakes
Tektro Auriga WS hydraulic 180 / Tektro Auriga WS hydraulic 160
Brake Levers
attached
Cockpit
Handlebar
MERIDA comp OS 660 R25
Headset
Conoid semi neck
Seat
Saddle
Juliet Sport
Seatpost
MERIDA comp SB12 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13.5" | 15" | 17" | 18.5" | 20" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.55 mm | 1.54 mm | 1.53 mm | 1.53 mm |
| Bottom Bracket Height | 292 mm | 292 mm | 292 mm | 292 mm | 292 mm |
| Front Center | 622 mm | 632 mm | 636 mm | 647 mm | 657 mm |
| Rake | 42 mm | 42 mm | 41 mm | 42 mm | 42 mm |
| Trail | 81 mm | 81 mm | 79 mm | 78 mm | 78 mm |
| Stack | 594 mm | 599 mm | 606 mm | 615 mm | 625 mm |
| Reach | 378 mm | 386 mm | 394 mm | 401 mm | 408 mm |
| Top Tube Length | 544 mm | 554 mm | 569 mm | 579 mm | 589 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 343 mm | 381 mm | 432 mm | 470 mm | 508 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 95 mm | 100 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1038 mm | 1048 mm | 1052 mm | 1063 mm | 1073 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 612 mm | 647 mm | 693 mm | 725 mm | 753 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
Model Overview
Juliet 7. 300 is part of the Merida Juliet model. There are 74 bikes that carry this model name. You can get a glimpse at all models from 2015, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Juliet 7. 300 components
Fork
This bike has the SunTour XCR Air fork installed. The fork’s travel is mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
As for the wheels, Merida Juliet 7. 300 2015, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Juliet 7. 300 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
