Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork Manitou Machete Comp
-
Groupset XT -
Suspension Hardtail -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
JULIET TFS
Suspension Fork
Manitou Machete Comp 100mm travel air fork with tapered steerer, 15mm bolt through axle with remote lockout
Drivetrain
Rear Derailleur
Shimano XT Shadow+
Front Derailleur
Shimano XT
Shift Levers
Shimano XT 22 speed rapid fire
Cassette
Shimano M7000, 11 speed, 11-42
Crank
Shimano XT 36-26 teeth
Bottom Bracket
BSA, 73mm, threaded
Chain
KMC X11-1
Wheels
Front Hub
Sealed bearing 15mm bolt through front and Shimano 4050 quick release rear, centerlock
Rear Hub
Sealed bearing 15mm bolt through front and Shimano 4050 quick release rear, centerlock
Rims
MERIDA Big 7 Comp CC
Spokes
Black stainless
Tires
Maxxis Ikon 27.5" x 2.2" folding
Brakes
Brakes
Shimano M500
Brake Levers
Shimano XT
Cockpit
Handlebar
MERIDA Comp 660mm wide 25mm rise
Headset
MERIDA M44PSE
Seat
Saddle
Female specific Juliet Sport V
Seatpost
MERIDA Comp 12mm, 27.2mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.55 mm | 1.52 mm | 1.51 mm |
| Bottom Bracket Height | 292 mm | 292 mm | 292 mm | 292 mm |
| Front Center | 629 mm | 640 mm | 650 | 661 mm |
| Rake | 38 mm | 39 mm | 39 mm | 39 mm |
| Trail | 92 mm | 91 mm | 88 mm | 88 mm |
| Stack | 594 mm | 599 mm | 606 mm | 615 mm |
| Reach | 378 mm | 386 mm | 399 mm | 407 mm |
| Top Tube Length | 544 mm | 554 mm | 569 mm | 579 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 343 mm | 381 mm | 432 mm | 470 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° | 70 ° |
| Head Tube Length | 95 mm | 100 mm | 105 mm | 115 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1045 mm | 1056 mm | 1066 mm | 1077 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 597 mm | 629 mm | 680 mm | 709 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
JULIET 7. XT-EDITION belongs to the Merida Juliet model. Merida released 74 bikes variations of this model so far. Take a sneak peek at all Merida Juliet bikes models from 2018, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Crosscountry bikes
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
JULIET 7. XT-EDITION weighs 12.04 kg (26.54 lbs) and is slightly lighter than the average. In conclusion, the average Crosscountry bike weighs 2.99% more than JULIET 7. XT-EDITION.
JULIET 7. XT-EDITION components
Fork
The JULIET 7. XT-EDITION comes factory-installed with the Manitou Machete Comp fork. This has a travel range of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When it comes to wheels, the JULIET 7. XT-EDITION bike is equipped with the 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida JULIET 7. XT-EDITION has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, it won’t be difficult to find the right one for you.
