Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 100mm -
Fork SunTour XCM HLO
-
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MATTS TFS
Suspension Fork
Suntour SR 26 XCM HLO 100
Drivetrain
Rear Derailleur
Shimano Alivio
Front Derailleur
Shimano M370
Shift Levers
Shimano Altus rapidfire
Cassette
Shimano CS-HG200-9 11-34
Crank
SR XCM 44-32-22 CG (BSA)
Bottom Bracket
BSA, threaded
Chain
KMC X9
Wheels
Front Hub
Alloy Disc / Alloy Disc cassette
Rear Hub
Alloy Disc / Alloy Disc cassette
Rims
MERIDA Matts Comp D
Spokes
Black stainless
Tires
MERIDA RACE 2.1
Brakes
Brakes
Tektro Auriga hydraulic 180 / Tektro Auriga hydraulic 160
Cockpit
Handlebar
MERIDA comp OS 660 R15
Headset
FSA No.11P
Seat
Saddle
MERIDA Sport 5
Seatpost
MERIDA comp SB12 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14.5" | 16" | 18" | 20" | 22" | 24" |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.48 mm | 1.45 mm | 1.45 mm | 1.44 mm | 1.48 mm |
| Front Center | 628 mm | 631 mm | 653 mm | 662 mm | 672 mm | 676 mm |
| Rake | 38 mm | 38 mm | 39 mm | 39 mm | 37 mm | 38 mm |
| Stack | 586 mm | 590 mm | 600 mm | 609 mm | 619 mm | 633 mm |
| Reach | 396 mm | 398 mm | 415 mm | 421 mm | 429 mm | 427 mm |
| Top Tube Length | 552 mm | 572 mm | 592 mm | 607 mm | 617 mm | 626 mm |
| Seat Tube Angle | 75 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 368 mm | 407 mm | 457 mm | 508 mm | 559 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 120 mm | 125 mm | 135 mm | 145 mm | 155 mm | 170 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1047 mm | 1050 mm | 1072 mm | 1081 mm | 1091 mm | 1095 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Standover Height | 680 mm | 708 mm | 753 mm | 790 mm | 829 mm | 869 mm |
| Wheels | 24" | 24" | 24" | 24" | 24" | 24" |
About this model
MATTS 6. 100 is part of the Merida Matts model. 172 bikes variations carry this model name so far. Take a sneak peek at all Merida Matts bikes models from 2016, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Youth bikes average price
If you want to purchase a solid Youth bike, it is important to know that the average cost is 278$. However, you could also get a good Youth bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Youth bikes average weight
Youth bikes have an average weight of 11.74 kg (25.88 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
MATTS 6. 100 weighs 14.2 kg (31.31 lbs) and is much heavier than the average. In conclusion, the average Youth bike weighs 20.95% less than MATTS 6. 100.
Overview of components
Fork
This bike has the SunTour XCM HLO fork installed. The fork’s travel is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the MATTS 6. 100 model has 24″ aluminum wheels. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
When you want to stop the bike in time, the brakes are vital. The MATTS 6. 100 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
