Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 26" -
Fork SunTour XCT -
Groupset Altus, Suntour SR -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MATTS SPEED
Suspension Fork
SR 26 XCT-HLO 100
Drivetrain
Rear Derailleur
Shimano Altus 9
Front Derailleur
Shimano Altus
Shift Levers
Shimano Altus rapidfire
Cassette
Sunrace CS-9S 11-32
Crank
SR XCM 44-32-22 CG
Bottom Bracket
Cartridge Bearing
Chain
KMC M99
Wheels
Front Hub
Alloy Disc / Alloy Disc cassette
Rear Hub
Alloy Disc / Alloy Disc cassette
Rims
MERIDA Matts D
Tires
MERIDA 26 2.1
Brakes
Brakes
Promax DSK hydraulic 160
Brake Levers
attached
Cockpit
Handlebar
MERIDA comp OS 660 R25
Headset
EGG steel-B
Seat
Saddle
MERIDA Sport 5
Seatpost
MERIDA speed 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14.5" | 16" | 18" | 20" | 22" | 24" |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.42 mm | 1.38 mm | 1.38 mm | 1.38 mm | 1.41 mm |
| Front Center | 626 mm | 630 mm | 651 mm | 661 mm | 671 mm | 676 mm |
| Rake | 42 mm | 38 mm | 38 mm | 39 mm | 38 mm | 38 mm |
| Stack | 567 mm | 571 mm | 581 mm | 590 mm | 600 mm | 614 mm |
| Reach | 396 mm | 403 mm | 421 mm | 427 mm | 434 mm | 434 mm |
| Top Tube Length | 552 mm | 572 mm | 592 mm | 607 mm | 617 mm | 627 mm |
| Seat Tube Angle | 75 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 368 mm | 407 mm | 457 mm | 508 mm | 559 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 120 mm | 125 mm | 135 mm | 145 mm | 155 mm | 170 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1045 mm | 1049 mm | 1070 mm | 1080 mm | 1090 mm | 1095 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Standover Height | 680 mm | 708 mm | 748 mm | 786 mm | 825 mm | 863 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" |
About this model
Matts 6. 40-D belongs to the Merida Matts model. 172 bikes variations carry this model name so far. You can easily view all of the Merida Matts bikes models from 2015, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Youth bikes average price
Our math shows that the average cost of a dependable Youth bike is 278$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Youth bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
Merida Matts 6. 40-D 2015 bike is equipped with the SunTour XCT fork, and has mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When it comes to wheels, the Matts 6. 40-D bike is equipped with the 26″ aluminum model. These wheels give you great handling over your bike. However, they provide less traction than 29″ wheels do.
Brakes
When you want to stop the bike in time, the brakes are vital. The Matts 6. 40-D has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
