Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCT
-
Groupset Alivio, Shimano -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MATTS 7. SPEED-D, material: aluminium, 27.5x2.25" max. wheelsize, 135x9mm axle standard, BSA bottom bracket standard
Suspension Fork
SR Suntour XCT30 HLO, Coil, 100mm suspension travel, Lockout, 27.5x2.25" max. wheelsize
Drivetrain
Rear Derailleur
Shimano ALIVIO SHADOW
Front Derailleur
Shimano M2000
Shift Levers
Shimano Altus
Cassette
Shimano HG200, 11-36 teeth, 9 speed
Crank
Shimano MT101, 40-30-22 teeth, 170 mm-XS, 175 mm-M up
Bottom Bracket
FSA TH-7420ST-W, CARTRIDGE BEARING
Chain
KMC M99
Wheels
Front Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP CC, 20mm inner width, material: aluminium
Spokes
Black steel
Tires
MERIDA K1080, 27.5x2.2", wire
Brakes
Brakes
Power DS100, 2 piston, hydraulic disc brake
Disk Rotors
Shimano RT10, 160 mm, 160mm
Cockpit
Handlebar
MERIDA COMP CC, material: aluminium, 660mm width, 25mm rise
Headset
FSA NO.10P 15
Seat
Saddle
MERIDA SPORT COMFORT
Seatpost
MERIDA CC, material: aluminium, 27.2mm diameter, 15mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.63 mm | 1.61 mm | 1.59 mm | 1.58 mm |
| Front Center | 617 mm | 628 mm | 638 mm | 649 mm |
| Rake | 39 mm | 40 mm | 39 mm | 39 mm |
| Stack | 596 mm | 601 mm | 612 mm | 622 mm |
| Reach | 366 mm | 374 mm | 386 mm | 393 mm |
| Top Tube Length | 530 mm | 540 mm | 555 mm | 565 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 343 mm | 381 mm | 432 mm | 470 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° | 70 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1033 mm | 1044 mm | 1054 mm | 1065 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 576 mm | 606 mm | 658 mm | 688 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
MATTS 7. 30 completes the Merida Matts model. There are 172 bikes that carry this model name. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Merida MATTS J12 2022 is the most economical model, with a starting price of 197$. Merida MATTS J. CHAMPION 2022 on the other hand costs 973$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Youth bikes average price
If you want to purchase a solid Youth bike, it is important to know that the average cost is 278$. However, even if your budget is less than the average, you might still be able to get a top-quality Youth bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
MATTS 7. 30 components
Fork
The MATTS 7. 30 comes factory-installed with the Suntour XCT fork. This has a travel range of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When it comes to wheels, the MATTS 7. 30 bike is equipped with the 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida MATTS 7. 30 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, it won’t take much to find one that’s right for you.
