Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCR Air
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MATTS 7. TFS, material: aluminium, 27.5 wheelsize, 135x9mm axle standard, BSA bottom bracket standard
Suspension Fork
Suntour XCR LOR, Air, 100mm suspension travel, Lockout, 42mm fork offset
Drivetrain
Rear Derailleur
Shimano XT Shadow
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore
Cassette
Shimano HG50, 11-36 teeth, 10 speed
Crank
FSA Alfa Drive, 36-22 teeth, 170 mm-XS, 175 mm-M up
Bottom Bracket
FSA TH-7420ST Cartridge Bearing
Chain
KMC X10
Wheels
Front Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TX505, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP CC, 20mm inner width, material: aluminium
Spokes
Black stainless
Tires
Maxxis Ikon, 27.5x2.2", fold
Brakes
Brakes
Shimano MT-200, 2 piston
Cockpit
Handlebar
MERIDA COMP CC, material: aluminium, 660mm width, 25mm rise
Headset
MERIDA M44PSE neck
Seat
Saddle
MERIDA COMP CC
Seatpost
MERIDA COMP CC, material: aluminium, 27.2mm diameter, 12mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.55 mm | 1.52 mm | 1.51 mm |
| Front Center | 629 mm | 640 mm | 650 | 661 mm |
| Rake | 38 mm | 39 mm | 39 mm | 39 mm |
| Stack | 594 mm | 599 mm | 606 mm | 615 mm |
| Reach | 378 mm | 386 mm | 399 mm | 407 mm |
| Top Tube Length | 544 mm | 554 mm | 569 mm | 579 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 343 mm | 381 mm | 432 mm | 470 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° | 70 ° |
| Head Tube Length | 95 mm | 100 mm | 105 mm | 115 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1045 mm | 1056 mm | 1066 mm | 1077 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
MATTS 7. 300 is part of the Merida Matts model. Merida released 172 bikes variations of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Merida MATTS J12 2020 is the most affordable bike of this model and has a price of 197$. On the other hand, Merida MATTS 7. 40 2020, is the most expensive and costs 608$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Youth bikes
If you want to purchase a solid Youth bike, it is important to know that the average cost is 278$. However, even if your budget is less than the average, you might still be able to get a top-quality Youth bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Youth bikes
On a deeper look, we notice that the average weight of a Youth bike is 11.74 kg (25.88 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
MATTS 7. 300 weighs 12.51 kg (27.58 lbs) and is a bit heavier than the average. In other words, this model is 6.56% heavier than the average Youth bike.
Overview of components
Fork
This bike has the SunTour XCR Air fork installed. The fork’s travel is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
As for the wheels, Merida MATTS 7. 300 2020, has a 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida MATTS 7. 300 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
MATTS 7. 300 comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, it won’t be difficult to find the right one for you.
