Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 27.5" -
Travel Front 100mm -
Fork RockShox Judy
-
Groupset Altus, Shimano -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MATTS 7. SPEED-D, material: aluminium, 27.5x2.25" max. wheelsize, 135x9mm axle standard, BSA bottom bracket standard
Suspension Fork
Rock Shox Judy TK, Coil, 100mm suspension travel Lockout, 42mm fork offset, 27.5x2.25" max. wheelsize
Drivetrain
Rear Derailleur
Shimano RD-M370
Front Derailleur
Shimano FD-M2020-TS [2s]
Shift Levers
Shimano ST-EF505-2L
Cassette
Shimano CS-HG200, 11-32 teeth, 9 speed
Crank
Shimano MT101-2, 36-22 teeth, 170 mm-XS/S, 175 mm-M/L
Bottom Bracket
BSA, threaded
Chain
KMC M99
Wheels
Front Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TX505, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA CC, 17mm inner width, material: aluminium
Spokes
Black steel
Tires
MERIDA K1080, 27.5x2.2", wire
Brakes
Brakes
Shimano ST-EF505, BR-MT200 brake caliper
Cockpit
Handlebar
MERIDA CC, material: aluminium, 640mm width, 25mm rise
Headset
FSA NO.10P Neck15
Seat
Saddle
MERIDA Sport comfort
Seatpost
MERIDA CC, material: aluminium, 27.2mm diameter, 15mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.63 mm | 1.61 mm | 1.59 mm | 1.58 mm |
| Front Center | 617 mm | 628 mm | 638 mm | 649 mm |
| Rake | 39 mm | 40 mm | 39 mm | 39 mm |
| Stack | 596 mm | 601 mm | 612 mm | 622 mm |
| Reach | 366 mm | 374 mm | 386 mm | 393 mm |
| Top Tube Length | 530 mm | 540 mm | 555 mm | 565 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 343 mm | 381 mm | 432 mm | 470 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° | 70 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1033 mm | 1044 mm | 1054 mm | 1065 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 576 mm | 606 mm | 658 mm | 688 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
MATTS 7. 60-2x completes the Merida Matts model. Merida released 172 bikes variations of this model so far. Take a sneak peek at all Merida Matts bikes models from 2021, by clicking here.
Model range prices
Merida MATTS J16 2021 is the cheapest bike model and costs 229$. Merida MATTS J. CHAMPION 2021 is the most expensive one and costs 702$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Youth bikes average price
According to our math, the average price for a trustworthy Youth bike is 278$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Youth bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2021 for 636$. Comparing the average cost of a Youth bike to this one, you will see that MATTS 7. 60-2x price is 128.78% more expensive.
MATTS 7. 60-2x components
Fork
The MATTS 7. 60-2x comes factory-installed with the RockShox Judy fork. This has a travel range of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When leaving the production line, the MATTS 7. 60-2x model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida MATTS 7. 60-2x is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, you won’t have a problem finding one that suits you.
