Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCR 32 Air
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MATTS 7. SPEED II, material: aluminium, 27.5x2.25" max. wheelsize, 135x9mm axle standard, BSA bottom bracket standard
Suspension Fork
SR Suntour XCR32 LOR, Air, 100mm suspension travel, Lockout, 42mm fork offset, 27.5x2.25" max. wheelsize
Drivetrain
Rear Derailleur
Shimano Deore M4120 SHADOW
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore M5100 / Shimano Deore M4100
Cassette
Shimano Deore M4100, 11-42 teeth, 10 speed
Crank
Shimano Deore M4100-2, 36-26 teeth, 170 mm-XS/S, 175 mm-M/L
Bottom Bracket
ATTACHED
Chain
KMC X10
Wheels
Front Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA CC, 17mm inner width, material: aluminium
Spokes
Black steel
Tires
MERIDA K1080, 27.5x2.2", wire
Brakes
Brakes
Power DS100, 2 piston, hydraulic disc brake
Disk Rotors
Shimano RT10, 160 mm
Cockpit
Handlebar
MERIDA COMP CC, material: aluminium, 660mm width, 25mm rise
Headset
FSA NO.10P 15
Seat
Saddle
MERIDA SPORT COMFORT
Seatpost
MERIDA CC, material: aluminium, 27.2mm diameter, 15mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.63 mm | 1.61 mm | 1.59 mm | 1.58 mm |
| Front Center | 617 mm | 628 mm | 638 mm | 649 mm |
| Rake | 39 mm | 40 mm | 39 mm | 39 mm |
| Stack | 596 mm | 601 mm | 612 mm | 622 mm |
| Reach | 366 mm | 374 mm | 386 mm | 393 mm |
| Top Tube Length | 530 mm | 540 mm | 555 mm | 565 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 343 mm | 381 mm | 432 mm | 470 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° | 70 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1033 mm | 1044 mm | 1054 mm | 1065 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 576 mm | 606 mm | 658 mm | 688 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
MATTS 7. 80 is a Merida Matts model. 172 bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Merida MATTS J12 2022 is the most economical model, with a starting price of 197$. Merida MATTS J. CHAMPION 2022 on the other hand costs 973$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Youth bikes average price
According to our calculations, the average cost of a Youth bike that is reliable is 278$. However, you could also get a good Youth bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The fork installed on this bike is the Suntour XCR 32 Air model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The MATTS 7. 80 2022 bike is equipped with 27.5″ aluminum wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida MATTS 7. 80 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
MATTS 7. 80 comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, you can easily find one that suits you.
