Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Reba
-
Groupset GX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
MD
168cm - 180cm
MD
168cm - 180cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NINETY-SIX CFA
Suspension Fork
Rock Shox Reba RL Air 15 100 oneloc
Rear Shock
Rock Shox Monarch RT3
Drivetrain
Rear Derailleur
SRAM GX 1 A1
Shift Levers
SRAM GX 11
Cassette
SRAM XG-1150-A1 10-42
Crank
FC S1000 32T(27.5") / 30T(29")
Chain
KMC X11-1
Wheels
Front Hub
FoBearing disc 15 Torque / FoBearing disc boost XD
Rear Hub
FoBearing disc 15 Torque / FoBearing disc boost XD
Rims
MERIDA Expert CC
Spokes
Black stainless
Tires
Maxxis Ikon 2.2 fold
Brakes
Brakes
SRAM Level T Centerline 180 PM / SRAM Level T Centerline 160 PM Stealth-a-majig
Brake Levers
SRAM Level T
Cockpit
Handlebar
MERIDA Expert OS 720 flat
Headset
Big Conoid A-bearing
Seat
Saddle
Prologo Kappa 3
Seatpost
MERIDA carbon Expert SB0 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD | MD | MD | LG | XL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.32 mm | 1.32 mm | 1.37 mm | 1.37 mm | 1.34 mm | 1.32 mm |
| Bottom Bracket Height | 353 mm | 353 mm | 353 mm | 334 mm | 334 mm | 334 mm | 334 mm |
| Front Center | 664 mm | 689 mm | 689 mm | 684 mm | 684 mm | 709 mm | 734 mm |
| Rake | 44 mm | 44 mm | 44 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 97 mm | 97 mm | 97 mm | 82 mm | 82 mm | 82 mm | 82 mm |
| Stack | 559 mm | 573 mm | 573 mm | 592 mm | 592 mm | 606 mm | 620 mm |
| Reach | 414 mm | 434 mm | 434 mm | 432 mm | 432 mm | 452 mm | 471 mm |
| Top Tube Length | 563 mm | 588 mm | 588 mm | 593 mm | 593 mm | 618 mm | 643 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 420 mm | 460 mm | 460 mm | 460 mm | 460 mm | 510 mm | 560 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 115 mm | 115 mm | 100 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1101 mm | 1126 mm | 1126 mm | 1129 mm | 1129 mm | 1154 mm | 1179 mm |
| Bottom Bracket Drop | 21 mm | 21 mm | 21 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Standover Height | 753 mm | 755 mm | 755 mm | 771 mm | 771 mm | 776 mm | 779 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 168 cm | 168 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 180 cm | 180 cm | 180 cm | 189 cm | 199 cm |
About this model
NINETY-SIX 6000 belongs to the Merida Ninety Six model. 46 bikes variations carry this model name so far. You can get a glimpse at all models from 2017, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Crosscountry bikes average weight
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Merida NINETY-SIX 6000 it’s weighing 11.65 kg (25.68 lbs). At this weight, is a bit lighter than average. In other words, this model is 6.44% lighter than the average Crosscountry bike.
Overview of components
Fork
Merida NINETY-SIX 6000 2017 bike is equipped with the RockShox Reba fork, and has 100mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The NINETY-SIX 6000 2017 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Merida NINETY-SIX 6000 bike has 7 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
