Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 100mm -
Fork RockShox SID
-
Groupset NX Eagle, X1 -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NINETY-SIX CF4 III, 100 mm suspension travel, material: carbon, 29x2.35" max. wheelsize, 148x12 mm axle standard, BSA bottom bracket standard
Suspension Fork
Rock Shox SID, Air, 120 mm suspension travel, Tapered, 3-Pos lockout, 44 mm fork offset, 29x2.6" max. wheelsize
Rear Shock
Fox Float Performance, adjustable low speed compression, platform
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
Trans-X JD-FL MX remote
Cassette
SRAM PG-1210 Eagle, 10-50 teeth, 12 speed
Crank
SRAM X1 Eagle DUB, 32 teeth, 170 mm-S, 175 mm-M up
Bottom Bracket
SRAM BB DUB BSA 73 MTB
Chain
SRAM SX Eagle
Wheels
Front Hub
Novatec SL-TEAM D041SB-B15, 110x15 mm width front hub, 32 spoke holes, 6 bolt
Rear Hub
Novatec SL-TEAM D462SB-S3S-B12-11S, 148x12 mm width rear hub, 32 spoke holes, 6 bolt
Rims
MERIDA EXPERT TR, 29 mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Spokes
Double Butted Black stainless
Tires
Maxxis Minion DHR II, 29x2.3", fold, TR EXO 3C MaxxTerra
Brakes
Brakes
SRAM Level Silver Stealth, 4 piston
Cockpit
Handlebar
MERIDA EXPERT CC, material: aluminium, 760 mm width, flat
Headset
Acros ICR MERIDA INTEGRATED neck, Upper and lower IPS sealing
Seat
Saddle
MERIDA COMP SL, V-mount, incl. MERIDA minitool
Seatpost
MERIDA COMP TR, 30.9 mm diameter, 0 mm setback, S: 125 mm travel seatpost - M/L: 150 mm travel seatpost - XL 175 mm travel seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.417 mm | 1.352 mm | 1.315 mm | 1.279 mm |
| Bottom Bracket Height | 338 mm | 338 mm | 338 mm | 338 mm |
| Front Center | 703 mm | 723 mm | 747 mm | 770 mm |
| Rake | 42 mm | 42 mm | 41 mm | 41 mm |
| Trail | 113 mm | 113 mm | 114 mm | 114 mm |
| Stack | 595 mm | 595 mm | 605 mm | 614 mm |
| Reach | 420 mm | 440 mm | 460 mm | 480 mm |
| Top Tube Length | 581 mm | 601 mm | 624 mm | 648 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 74.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1136 mm | 1156 mm | 1180 mm | 1203 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm | 36 mm |
| Standover Height | 740 mm | 741 mm | 747 mm | 749 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
NINETY-SIX 6000 is part of the Merida Ninety Six model. There are 52 bikes that carry this model name. Take a sneak peek at all Merida Ninety Six bikes models from 2024, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
The fork installed on this bike is the RockShox SID model. The travel on this model is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The NINETY-SIX 6000 has a rear shock with a travel of 100mm. The model Fox Float Performance is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The NINETY-SIX 6000 2024 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The NINETY-SIX 6000 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Merida NINETY-SIX 6000 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Merida NINETY-SIX 6000 includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
