Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Travel Rear 96mm -
Fork Fox Factory Float 32
-
Groupset XTR -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
LG
177cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NINETY-SIX CF5, 96mm suspension travel, material: carbon, 29 wheelsize, 148x12mm axle standard, BB92 bottom bracket standard
Suspension Fork
Fox Factory 32 Float SC, Air, 100mm suspension travel, Tapered, Remote lockout, 44mm fork offset
Rear Shock
FOX Factory Float, remote lockout
Drivetrain
Rear Derailleur
Shimano XTR Shadow+
Shift Levers
Shimano XTR
Cassette
Shimano XTR, 10-51 teeth, 12 speed
Crank
Shimano XTR, 34 teeth, 175mm-M up
Bottom Bracket
Shimano BB94-41A Pressfit
Chain
Shimano M9100
Wheels
Rims
Reynolds TR 249, 110x15mm width front hub, 148x12mm width rear hub, 24mm inner width, Centerlock, Shimano 12 Speed, material: carbon, Tubeless ready (tubeless tape and valves included)
Tires
Continental Race King 2.2, 29x2.2", fold, RaceSport
Brakes
Brakes
Shimano XTR, 2 piston
Cockpit
Handlebar
MERIDA TEAM CC, material: carbon, 720mm width, flat
Headset
FSA NO.55E
Seat
Saddle
Prologo Scratch 2
Seatpost
MERIDA TEAM CC, material: carbon, 30.9mm diameter, 0mm setback, S-Flex
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.35 mm | 1.32 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm |
| Front Center | 684 mm | 709 mm | 734 mm |
| Rake | 51 mm | 51 mm | 52 mm |
| Trail | 82 mm | 82 mm | 81 mm |
| Stack | 581 mm | 595 mm | 609 mm |
| Reach | 421 mm | 441 mm | 460 mm |
| Top Tube Length | 582 mm | 607 mm | 632 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 460 mm | 510 mm | 560 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1110 mm | 1135 mm | 1160 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm |
| Standover Height | 760 mm | 765 mm | 768 mm |
| Wheels | 29" | 29" | 29" |
| Rider Max Height | 183 cm | 190 cm | cm |
About this model
NINETY-SIX 9. 9000 is part of the Merida Ninety Six model. Merida launched 46 bikes of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Crosscountry bikes average weight
If we make a quick analysis of the average weight of a Crosscountry bike, we get 12.4 kg (27.34 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 9.85 kg (21.72 lbs), Merida bike is much lighter than average. In other words, this model is 25.89% lighter than the average Crosscountry bike.
NINETY-SIX 9. 9000 components
Fork
Merida NINETY-SIX 9. 9000 2020 bike is equipped with the Fox Factory Float 32 fork, and has 100mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the FOX Factory Float rear shock model, which has a travel of 96mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The wheels on NINETY-SIX 9. 9000 are the 29″ carbon type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The NINETY-SIX 9. 9000 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
