Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 100mm -
Fork Fox Factory Float 34
-
Groupset GX Eagle Transmission, SRAM -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NINETY-SIX CF4 III, 100 mm suspension travel, material: carbon, 29x2.35" max. wheelsize, 148x12 mm axle standard, BSA bottom bracket standard
Suspension Fork
Fox 34 Float SC Factory, Air, 120 mm suspension travel, Tapered, 3 Pos lockout, 44 mm fork offset, 29x2.4" max. wheelsize
Rear Shock
Fox Float Factory, adjustable low speed compression, platform
Drivetrain
Rear Derailleur
SRAM GX Eagle Transmission AXS, wireless, T-Type
Shift Levers
SRAM AXS POD Controller
Cassette
SRAM GX Eagle Transmission, 10-52 teeth, 12 speed
Crank
SRAM GX Eagle Transmission, 32 teeth
Bottom Bracket
SRAM BB DUB BSA 73 MTB WIDE
Chain
SRAM GX Eagle Transmission, Flattop
Wheels
Rims
Reynolds TR 309/289 XC, 110x15 mm width front hub, 148x12 mm width rear hub, 30/28 mm inner width, Centerlock, SRAM XD, material: carbon, Tubeless ready (tubeless tape and valves included), Lifetime warranty
Tires
Maxxis Minion DHR II, 29x2.3", fold, TR EXO 3C MaxxTerra
Brakes
Brakes
SRAM Level Silver Stealth, 4 piston, 2 piston
Cockpit
Handlebar
MERIDA EXPERT CC, material: aluminium, 760 mm width, flat
Headset
Acros ICR MERIDA INTEGRATED neck, Upper and lower IPS sealing
Seat
Saddle
SCRATCH M5 PAS TIROX, V-mount adapter, incl. MERIDA minitool
Seatpost
Rock Shox Reverb AXS, 30.9 mm diameter, 0 mm setback, S:125 mm travel seatpost - M 150 mm travel seatpost - L/XL 170 mm travel seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.417 mm | 1.352 mm | 1.315 mm | 1.279 mm |
| Bottom Bracket Height | 338 mm | 338 mm | 338 mm | 338 mm |
| Front Center | 703 mm | 723 mm | 747 mm | 770 mm |
| Rake | 42 mm | 42 mm | 41 mm | 41 mm |
| Trail | 113 mm | 113 mm | 114 mm | 114 mm |
| Stack | 595 mm | 595 mm | 605 mm | 614 mm |
| Reach | 420 mm | 440 mm | 460 mm | 480 mm |
| Top Tube Length | 581 mm | 601 mm | 624 mm | 648 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 74.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1136 mm | 1156 mm | 1180 mm | 1203 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm | 36 mm |
| Standover Height | 740 mm | 741 mm | 747 mm | 749 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
NINETY-SIX 9000 belongs to the Merida Ninety Six model. There are 52 bikes that carry this model name. Take a sneak peek at all Merida Ninety Six bikes models from 2024, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
NINETY-SIX 9000 components
Fork
Merida NINETY-SIX 9000 2024 bike is equipped with the Fox Factory Float 34 fork, and has 120mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The NINETY-SIX 9000 has a rear shock with a travel of 100mm. The model Fox Float Factory is the one installed in this bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The wheels on NINETY-SIX 9000 are the 29″ carbon type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The NINETY-SIX 9000 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
NINETY-SIX 9000 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
