Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork Fox Performance Float 32
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NINETY-SIX RC CF4 III, 100mm suspension travel, material: carbon, 29x2.3" max. wheelsize, 148x12mm axle standard, BSA bottom bracket standard
Suspension Fork
FOX 32 Float SC Performance, Air, 100mm suspension travel, Tapered, Remote lockout, 44mm fork offset
Rear Shock
FOX Float DPS Performance Elite, remote lockout
Drivetrain
Rear Derailleur
Shimano XT M8100 Shadow+, SGS
Shift Levers
JD-FL lever
Cassette
Shimano XT, 10-51 teeth, 12 speed
Crank
Shimano XT, 32 teeth, 170 mm-S, 175 mm-M up
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano SLX
Wheels
Front Hub
Shimano SLX, 110x15mm width front hub, 32 spoke holes, Centerlock
Rear Hub
Shimano SLX, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA EXPERT CC, 22.8mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Spokes
Double Butted Black stainless
Tires
Maxxis Rekon Race, 29x2.25", fold, TR EXO
Brakes
Brakes
Shimano XT, 2 piston
Disk Rotors
Shimano RT54, 180 mm, 160 mm
Cockpit
Handlebar
MERIDA EXPERT CC, material: aluminium, 760mm width, flat
Headset
MERIDA 8151
Seat
Saddle
MERIDA EXPERT CC, incl. MERIDA minitool
Seatpost
MERIDA EXPERT TR LIGHT, 30.9mm diameter, 0mm setback, S/M/L/XL: 100mm travel seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.351 mm | 1.291 mm | 1.258 mm | 1.225 mm |
| Bottom Bracket Height | 329 mm | 329 mm | 329 mm | 329 mm |
| Front Center | 695 mm | 715 mm | 738 mm | 762 mm |
| Rake | 44 mm | 44 mm | 43 mm | 44 mm |
| Trail | 100 mm | 100 mm | 101 mm | 100 mm |
| Stack | 585 mm | 585 mm | 595 mm | 604 mm |
| Reach | 433 mm | 453 mm | 473 mm | 493 mm |
| Top Tube Length | 576 mm | 596 mm | 619 mm | 643 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1126 mm | 1146 mm | 1169 mm | 1193 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 730 mm | 731 mm | 736 mm | 738 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
NINETY-SIX RC XT is a Merida Ninety Six model. There are 46 bikes that carry this model name. You can easily view all of the Merida Ninety Six bikes models from 2022, here.
Model range prices
Merida NINETY-SIX RC 5000 2022 is the cheapest bike model and costs 3757$. Merida NINETY-SIX RC 10K 2022 is the most expensive one and costs 11556$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Merida released this model in 2022, its price was 4266$. Comparing this to the average Crosscountry bike price, we see that the price is 123.94% more expensive.
NINETY-SIX RC XT components
Fork
Merida NINETY-SIX RC XT 2022 bike is equipped with the Fox Performance Float 32 fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the FOX Float DPS Performance Elite rear shock model, which has a travel of 100mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The NINETY-SIX RC XT 2022 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
NINETY-SIX RC XT comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Merida NINETY-SIX RC XT comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
