Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork Fox Performance Float 32
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NINETY-SIX RC CF4 III, 100mm suspension travel, material: carbon, 29x2.3" max. wheelsize, 148x12mm axle standard, BSA bottom bracket standard
Suspension Fork
FOX 32 Float SC Performance, Air, 100mm suspension travel, Tapered, Remote lockout, 44mm fork offset
Rear Shock
FOX Float DPS Performance Elite, remote lockout
Drivetrain
Rear Derailleur
Shimano XT M8100 Shadow+, SGS
Shift Levers
JD-FL lever
Cassette
Shimano XT, 10-51 teeth, 12 speed
Crank
Shimano XT, 32 teeth, 170 mm-S, 175 mm-M up
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano SLX
Wheels
Front Hub
Shimano SLX, 110x15mm width front hub, 32 spoke holes, Centerlock
Rear Hub
Shimano SLX, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA EXPERT CC, 22.8mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Spokes
Double Butted Black stainless
Tires
Maxxis Rekon Race, 29x2.25", fold, TR EXO
Brakes
Brakes
Shimano XT / Shimano XT M8110, 2 piston, 2 piston, flat mount
Cockpit
Handlebar
MERIDA EXPERT CC, material: aluminium, 760mm width, flat
Headset
MERIDA 8151
Seat
Saddle
MERIDA EXPERT CC, incl. MERIDA minitool
Seatpost
MERIDA EXPERT TR LIGHT, 30.9mm diameter, 0mm setback, S/M/L/XL: 100mm travel seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.351 mm | 1.291 mm | 1.258 mm | 1.225 mm |
| Bottom Bracket Height | 329 mm | 329 mm | 329 mm | 329 mm |
| Front Center | 695 mm | 715 mm | 738 mm | 762 mm |
| Rake | 44 mm | 44 mm | 43 mm | 44 mm |
| Trail | 100 mm | 100 mm | 101 mm | 100 mm |
| Stack | 585 mm | 585 mm | 595 mm | 604 mm |
| Reach | 433 mm | 453 mm | 473 mm | 493 mm |
| Top Tube Length | 576 mm | 596 mm | 619 mm | 643 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1126 mm | 1146 mm | 1169 mm | 1193 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 730 mm | 731 mm | 736 mm | 738 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
NINETY-SIX RC XT belongs to the Merida Ninety Six model. There are 46 bikes that carry this model name. Take a sneak peek at all Merida Ninety Six bikes models from 2023, by clicking here.
Model range prices
Merida NINETY-SIX RC 5000 2023 is the cheapest bike model and costs 3757$. Merida NINETY-SIX RC 10K 2023 is the most expensive one and costs 11556$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2023 and its price was 4266$. In conclusion, this bike price is 123.94% more expensive than the price of the average Crosscountry bike.
NINETY-SIX RC XT components
Fork
The fork installed on this bike is the Fox Performance Float 32 model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this bike is FOX Float DPS Performance Elite, with a travel distance of 100mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the NINETY-SIX RC XT bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida NINETY-SIX RC XT is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Merida NINETY-SIX RC XT includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
