Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 29" -
Groupset XX1 -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
MD
168cm - 180cm
MD
168cm - 180cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NINETY-SIX CF5
Suspension Fork
Rock Shox RS1 PSSA100
Rear Shock
Rock Shox Monarch XX remote
Drivetrain
Rear Derailleur
SRAM XX1 11s
Shift Levers
SRAM XX1 trigger
Cassette
CS XG1195 10-42T
Crank
SRAM XX1 29":32T / 27.5":34T (BB92)
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM PCXX1
Wheels
Rims
DT Swiss XR1501 Spline One PS15-R12
Tires
Maxxis Ikon 2.2 3C
Brakes
Brakes
Guide Ultimate 180 disc / Guide Ultimate 160 disc Stealth-a-majig
Cockpit
Handlebar
PRC Team carbon 720 Flat
Headset
FSA No.55 E
Seat
Saddle
Prologo new Nago Evo X10 TiroX
Seatpost
PRC Double carbon superlite 27.2 SB0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD | MD | MD | LG | XL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.32 mm | 1.32 mm | 1.37 mm | 1.37 mm | 1.34 mm | 1.32 mm |
| Bottom Bracket Height | 353 mm | 353 mm | 353 mm | 334 mm | 334 mm | 334 mm | 334 mm |
| Front Center | 664 mm | 689 mm | 689 mm | 684 mm | 684 mm | 709 mm | 734 mm |
| Rake | 44 mm | 44 mm | 44 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 97 mm | 97 mm | 97 mm | 82 mm | 82 mm | 82 mm | 82 mm |
| Stack | 559 mm | 573 mm | 573 mm | 592 mm | 592 mm | 606 mm | 620 mm |
| Reach | 414 mm | 434 mm | 434 mm | 432 mm | 432 mm | 452 mm | 471 mm |
| Top Tube Length | 563 mm | 588 mm | 588 mm | 593 mm | 593 mm | 618 mm | 643 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 420 mm | 460 mm | 460 mm | 460 mm | 460 mm | 510 mm | 560 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 115 mm | 115 mm | 100 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1101 mm | 1126 mm | 1126 mm | 1129 mm | 1129 mm | 1154 mm | 1179 mm |
| Bottom Bracket Drop | 21 mm | 21 mm | 21 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Standover Height | 753 mm | 755 mm | 755 mm | 771 mm | 771 mm | 776 mm | 779 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 168 cm | 168 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 180 cm | 180 cm | 180 cm | 189 cm | 199 cm |
About this model
NINETY-SIX TEAM completes the Merida Ninety Six model. There are 46 bikes that carry this model name. Take a sneak peek at all Merida Ninety Six bikes models from 2016, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Enduro bikes average price
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, this doesn’t mean that if you spend less money on an Enduro bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Enduro bikes
Enduro bikes have an average weight of 14.27 kg (31.46 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Merida NINETY-SIX TEAM it’s weighing 9.81 kg (21.63 lbs). At this weight, is much lighter than average. In other words, this model is 45.46% lighter than the average Enduro bike.
Overview of components
Wheels size
The wheels on NINETY-SIX TEAM are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida NINETY-SIX TEAM has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
NINETY-SIX TEAM comes in 7 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
