Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 29" -
Travel Front 100mm -
Travel Rear 96mm -
Fork Fox Factory Float 32
-
Groupset XX1 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NINETY-SIX CF5
Suspension Fork
Fox Factory 32 Float SC, Air, 100mm suspension travel, Tapered, Remote lockout
Rear Shock
FOX Factory Float, remote lockout
Drivetrain
Rear Derailleur
SRAM XX1 Eagle
Front Derailleur
High direct mount (none included)
Shift Levers
no / SRAM XX1 Eagle
Cassette
SRAM XG 1299 Eagle, 10-50 teeth, 12 speed
Crank
SRAM XX1 Eagle, 34 teeth
Bottom Bracket
SRAM BB DUB press-fit MTB 92
Chain
SRAM XX1 Eagle
Chain Guide
N/A
Pedals
None included
Wheels
Front Hub
attached
Rear Hub
attached
Rims
Fulcrum Red Passion 3, 110x15mm width front hub, 148x12mm width rear hub,mm inner width 21, 6 bolt, SRAM XD
Spokes
attached
Tires
Maxxis Ikon, 29x2.2", fold, 3C
Brakes
Brakes
SRAM Level Ultimate
Brake Levers
SRAM Level Ultimate
Cockpit
Stem
Merida Team CC, 31.8mm diameter, -17° stem angle
Handlebar
MERIDA Team CC, 720mm width, flat
Grips
Merida Team CC
Headset
FSA NO.55E, 2191018117
Seat
Saddle
Prologo Scratch 2
Seatpost
KS ZETA, 30.9mm diameter, 0mm setback, 50mm travel seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.35 mm | 1.32 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm |
| Front Center | 684 mm | 709 mm | 734 mm |
| Rake | 51 mm | 51 mm | 52 mm |
| Trail | 82 mm | 82 mm | 81 mm |
| Stack | 581 mm | 595 mm | 609 mm |
| Reach | 421 mm | 441 mm | 460 mm |
| Top Tube Length | 582 mm | 607 mm | 632 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 460 mm | 510 mm | 560 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1110 mm | 1135 mm | 1160 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm |
| Standover Height | 760 mm | 765 mm | 768 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
NINETY-SIX TEAM completes the Merida Ninety Six model. 46 bikes variations carry this model name so far. Take a sneak peek at all Merida Ninety Six bikes models from 2019, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Crosscountry bikes
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Merida NINETY-SIX TEAM it’s weighing 10.05 kg (22.16 lbs). At this weight, is much lighter than average. In short, the average Crosscountry bike weight is 23.38% higher than this one.
Overview of components
Fork
This bike has the Fox Factory Float 32 fork installed. The fork’s travel is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
As for the rear shock, this bike has the FOX Factory Float model, with a travel of 96mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The wheels on NINETY-SIX TEAM are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The NINETY-SIX TEAM comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the NINETY-SIX TEAM. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
