Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 29" -
Travel Front 100mm -
Travel Rear 96mm -
Fork Fox Rhythm Float 32
-
Groupset XT -
Suspension Full -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NINETY-SIX CFA
Suspension Fork
Fox Rhythm 32 Float, Air, 100mm suspension travel, Tapered, Remote lockout
Rear Shock
FOX Performance Elite Float, remote lockout
Drivetrain
Rear Derailleur
Shimano XT Shadow+
Front Derailleur
Shimano XT
Shift Levers
Shimano XT
Cassette
Shimano M7000, 11-42 teeth, 11 speed
Crank
Shimano XT, 34-24 teeth
Bottom Bracket
BSA, 73mm, threaded
Chain
KMC X11
Chain Guide
N/A
Pedals
None included
Wheels
Front Hub
Shimano Deore, 110x15mm width, 32 spoke holes, Centerlock / Shimano Deore, 148x12mm width, 32 spoke holes, Centerlock
Rear Hub
Shimano Deore, 110x15mm width, 32 spoke holes, Centerlock / Shimano Deore, 148x12mm width, 32 spoke holes, Centerlock
Rims
MERIDA Expert CC, 22.8mm inner width
Spokes
Double Butted Black stainless
Tires
Maxxis Ikon, 29x2.2", fold
Brakes
Brakes
Shimano XT
Brake Levers
Shimano XT
Cockpit
Stem
Merida Expert CC, 31.8mm diameter, -17° stem angle
Handlebar
MERIDA Expert CC, 720mm width, flat
Grips
Merida Expert EC
Headset
FSA NO.55E, 2191018117
Seat
Saddle
Prologo Scratch
Seatpost
MERIDA Expert CC, 30.9mm diameter, 0mm setback, Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.35 mm | 1.32 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm |
| Front Center | 684 mm | 709 mm | 734 mm |
| Rake | 51 mm | 51 mm | 52 mm |
| Trail | 82 mm | 82 mm | 81 mm |
| Stack | 581 mm | 595 mm | 609 mm |
| Reach | 421 mm | 441 mm | 460 mm |
| Top Tube Length | 582 mm | 607 mm | 632 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 460 mm | 510 mm | 560 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1110 mm | 1135 mm | 1160 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm |
| Standover Height | 760 mm | 765 mm | 768 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
NINETY-SIX XT belongs to the Merida Ninety Six model. Merida released 46 bikes variations of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Crosscountry bikes
On a deeper look, we notice that the average weight of a Crosscountry bike is 12.4 kg (27.34 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 12.34 kg (27.21 lbs), Merida bike is slightly lighter than average. In other words, this model is 0.49% lighter than the average Crosscountry bike.
NINETY-SIX XT components
Fork
The NINETY-SIX XT comes factory-installed with the Fox Rhythm Float 32 fork. This has a travel range of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
As for the rear shock, this bike has the FOX Performance Elite Float model, with a travel of 96mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, Merida NINETY-SIX XT 2019, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida NINETY-SIX XT has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
