Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 26" -
Travel Front 160mm -
Fork SunTour DUROLUX36
-
Groupset Deore -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
One-Sixty-D-Single BSC VPP A-Link R12
Suspension Fork
SR Suntour Durolux RC2 20 QLC DS 26" 160 CTS
Rear Shock
Fox Float CTD BV LV - Perf.
Drivetrain
Rear Derailleur
Shimano Deore Shadow+
Front Derailleur
Shimano Deore H35 double
Shift Levers
Shimano Deore ispec
Cassette
Shimano CS-HG-10 11-36
Crank
Shimano Deore 38-24
Bottom Bracket
attached
Chain
KMC X10 10s
Wheels
Front Hub
Shimano Zen-20 Cen / Shimano Deore XT-12 Cen
Rear Hub
Shimano Zen-20 Cen / Shimano Deore XT-12 Cen
Rims
Alex MD23-26 Disc
Spokes
black stainless
Tires
Schwalbe Hans Dampf 2.4 Evo fold
Brakes
Brakes
Shimano M615 203 mm Cen / Shimano M615 180 mm Cen
Brake Levers
attached
Cockpit
Handlebar
FSA V-Drive Riser 740 R15
Headset
Big Conoid semi Neck
Seat
Saddle
Selle Italia X1
Seatpost
FSA V-Drive 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.46 mm | 1.42 mm | 1.38 mm |
| Bottom Bracket Height | 333 mm | 333 mm | 333 mm | 333 mm |
| Stack | 578 mm | 587 mm | 600 mm | 610 mm |
| Reach | 391 mm | 403 mm | 424 mm | 441 mm |
| Top Tube Length | 557 mm | 572 mm | 597 mm | 617 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 380 mm | 432 mm | 482 mm | 530 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 110 mm | 120 mm | 135 mm | 145 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Bottom Bracket Drop | 10 mm | 10 mm | 10 mm | 10 mm |
| Wheels | 26" | 26" | 26" | 26" |
Model Overview
One-Sixty 5 is part of the Merida One Sixty model. Merida launched 37 bikes of this model so far. You can get a glimpse at all models from 2014, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro bikes average price
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Enduro bikes average weight
If we make a quick analysis of the average weight of an Enduro bike, we get 14.27 kg (31.46 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 15.28 kg (33.69 lbs), Merida bike is a bit heavier than average. To sum up, it’s 7.08% heavier than the average weight of Enduro bikes.
One-Sixty 5 components
Fork
This bike has the SunTour DUROLUX36 fork installed. The fork’s travel is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The One-Sixty 5 2014 bike is equipped with 26″ aluminum wheels when leaving the factory. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The One-Sixty 5 comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
