Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 170mm -
Travel Rear 171mm -
Fork RockShox Domain
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ONE-SIXTY LITE III, 171 mm suspension travel mullet / 162 mm suspension travel 29", material: aluminium, 29x2.5" max. wheelsize, 148x12 mm axle standard, BSA bottom bracket standard
Suspension Fork
Rock Shox Domain R, Air, 170 mm suspension travel, Tapered, 44 mm fork offset, 29.5x2.8" max. wheelsize
Rear Shock
Rock Shox Deluxe Select+, lockout
Drivetrain
Rear Derailleur
Shimano Deore M6100, SGS
Shift Levers
Shimano SL-MT500-IL / Shimano Deore M6100
Cassette
Shimano Deore M6100, 10-51 teeth, 12 speed
Crank
Shimano Deore MT512, 32 teeth, 170 mm for all sizes
Bottom Bracket
Shimano BB-MT-501, 24 mm
Chain
KMC X12
Chain Guide
MERIDA EXPERT TR ISCG05
Wheels
Front Hub
Shimano TC500-B / Shimano TC500-MS-B, 110x15 mm width front hub, 32 spoke holes, Centerlock, 148x12 mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TC500-B / Shimano TC500-MS-B, 110x15 mm width front hub, 32 spoke holes, Centerlock, 148x12 mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP TR II, 28 mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included), rear 27.5" up to Size M / L & XL rear 29"
Spokes
Double Butted Black stainless
Tires
Front: Maxxis Assegai, 29x2.5", fold, TR EXO+ 3C MaxxGrip, Rear: Maxxis DHR II, 27.5x2.4" XS/S/M 29x2.4" L/XL, fold, TR DD 3C MaxxTerra
Brakes
Brakes
Shimano Deore M6120, 4 piston
Cockpit
Stem
MERIDA EXPERT eTRII, material: aluminium, 35 mm diameter, 0° stem angle, 40 mm
Handlebar
MERIDA EXPERT TR II, material: aluminium, 780 mm width, XS/S 18 mm rise, M/L/XL 30 mm rise
Headset
Acros ICR MERIDA EXTERNAL neck, Upper and lower IPS sealing
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA EXPERT TR II, 34.9 mm diameter, 0 mm setback, XS/S: 150 mm travel seatpost - M: 170 mm travel seatpost - L/XL: 200 mm travel seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XShort | Short | Mid | Long | XLong |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.482 mm | 1.391 mm | 1.309 mm | 1.255 mm | 1.215 mm |
| Front Center | 754 mm | 781 mm | 808 mm | 839 mm | 872 mm |
| Rake | 38 mm | 38 mm | 37 mm | 44 mm | 44 mm |
| Trail | 140 mm | 140 mm | 141 mm | 134 mm | 134 mm |
| Stack | 615 mm | 615 mm | 615 mm | 625 mm | 638 mm |
| Reach | 415 mm | 442 mm | 470 mm | 498 mm | 525 mm |
| Top Tube Length | 535 mm | 562 mm | 589 mm | 621 mm | 653 mm |
| Seat Tube Angle | 79 ° | 79 ° | 79 ° | 79 ° | 79 ° |
| Seat Tube Length | 400 mm | 410 mm | 425 mm | 445 mm | 470 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 95 mm | 95 mm | 95 mm | 105 mm | 120 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 437 mm | 437 mm |
| Wheelbase | 1188 mm | 1215 mm | 1242 mm | 1275 mm | 1308 mm |
| Bottom Bracket Drop | 7 mm | 7 mm | 7 mm | 27 mm | 27 mm |
| Standover Height | 735 mm | 740 mm | 743 mm | 740 mm | 735 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
ONE-SIXTY 500 belongs to the Merida One Sixty model. There are 42 bikes that carry this model name. Check out the entire range from 2024 of this model, by clicking this link.
Model range prices
Merida ONE-SIXTY 700 2024 is the most affordable bike of this model and has a price of 3146$. On the other hand, Merida ONE-SIXTY 8000 2024, is the most expensive and costs 6099$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Enduro bikes average price
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
ONE-SIXTY 500 components
Fork
The fork installed on this bike is the RockShox Domain model. The travel on this model is 170mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
From the factory, it comes with the Rock Shox Deluxe Select+ rear shock model, which has a travel of 171mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When leaving the production line, the ONE-SIXTY 500 model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Dropper post
The Merida model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
