Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 26" -
Travel Front 120mm -
Groupset XT, Deore -
Suspension Full -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
One-Twenty Comp-D BC A-Link
Suspension Fork
Rock Shox XC 32TK 120 taper
Rear Shock
SR Suntour Epicon Lorp
Drivetrain
Rear Derailleur
Shimano Deore XT Shadow
Front Derailleur
Shimano Deore H35 triple
Shift Levers
Shimano Deore
Cassette
Shimano CS-HG-10 11-36
Crank
Shimano M522 Octa 42-32-24
Bottom Bracket
Shimano Octalink
Chain
KMC X10 10s
Wheels
Front Hub
Shimano M435 Cen
Rear Hub
Shimano M435 Cen
Rims
MERIDA Matts Comp D
Spokes
black stainless
Tires
MERIDA Trail Lite 2.25 KV
Brakes
Brakes
Shimano M445 180 mm Cen
Brake Levers
attached
Cockpit
Handlebar
MERIDA Comp OS 680 R25
Headset
Big Conoid semi Neck
Seat
Saddle
MERIDA Pro SI
Seatpost
Merida Comp SB12 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.31 mm | 1.31 mm | 1.32 mm |
| Stack | 548 mm | 548 mm | 562 mm | 581 mm |
| Reach | 399 mm | 419 mm | 429 mm | 439 mm |
| Top Tube Length | 563 mm | 583 mm | 598 mm | 613 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 410 mm | 460 mm | 510 mm | 560 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 120 mm | 120 mm | 135 mm | 155 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheels | 26" | 26" | 26" | 26" |
About this model
One-Twenty 500 completes the Merida One Twenty model. Merida launched 86 bikes of this model so far. Take a sneak peek at all Merida One Twenty bikes models from 2014, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Trail bikes average weight
On a deeper look, we notice that the average weight of a Trail bike is 12.98 kg (28.62 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 13.99 kg (30.84 lbs), Merida bike is a bit heavier than average. To sum up, it’s 7.78% heavier than the average weight of Trail bikes.
Overview of components
Wheels
When leaving the production line, the One-Twenty 500 model has 26″ aluminum wheels. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida One-Twenty 500 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
