Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 27.5" / 29" -
Travel Front 130mm -
Fork SunTour RAIDON
-
Groupset Deore, FSA -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ONE-TWENTY LITE
Suspension Fork
Suntour Raidon34, Air, 130mm suspension travel, Tapered, lockout
Rear Shock
Suntour Unair TR LOR8, lockout
Drivetrain
Rear Derailleur
Shimano Deore Shadow+
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore / Shimano Deore
Cassette
Shimano HG500, 11-42 teeth, 10 speed
Crank
FSA Comet Modular MegaExo 36-26 teeth
Chain
KMC X10
Wheels
Front Hub
Shimano MT400-B, 110x15mm width, 32 spoke holes, Centerlock / Shimano MT400-B, 148x12mm width, 32 spoke holes, Centerlock
Rear Hub
Shimano MT400-B, 110x15mm width, 32 spoke holes, Centerlock / Shimano MT400-B, 148x12mm width, 32 spoke holes, Centerlock
Rims
MERIDA Comp CC, 20mm inner width
Spokes
Black stainless
Tires
Maxxis Forekaster, 29x2.35" / 27.5x2.35", fold, TR EXO Dual
Brakes
Brakes
Shimano MT-200
Brake Levers
Shimano MT-200
Cockpit
Handlebar
MERIDA Expert CC, 740mm width, 10mm rise
Headset
FSA NO.47/50, 2191027082
Seat
Saddle
MERIDA Comp CC
Seatpost
MERIDA EXPERT TR, 30.9mm diameter, 0mm setback, S: 100mm travel seatpost - M/L/XL 125mm travel seatpost,
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM | MD | MD | SM/MD | MD | MD | LG | XL |
|---|---|---|---|---|---|---|---|---|---|
| Wheels | 27" | 29" | 27" | 29" | 27" | 27" | 29" | 29" | 29" |
About this model
ONE-TWENTY 500 is a Merida One Twenty model. Merida released 86 bikes variations of this model so far. You can easily view all of the Merida One Twenty bikes models from 2019, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Trail bikes average weight
If we make a quick analysis of the average weight of a Trail bike, we get 12.98 kg (28.62 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Merida ONE-TWENTY 500 it’s weighing 14.52 kg (32.01 lbs). At this weight, is considerably heavier than average. In other words, this model is 11.86% heavier than the average Trail bike.
Overview of components
Fork
Merida ONE-TWENTY 500 2019 bike is equipped with the SunTour RAIDON fork, and has 130mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When it comes to wheels, the ONE-TWENTY 500 bike is equipped with the 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida ONE-TWENTY 500 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Dropper post
Every bike should have a dropper post, and this one does. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
