Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Marzocchi Bomber Z2
-
Groupset XT, Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ONE-TWENTY LITE, 120mm suspension travel, material: aluminium, 29 wheelsize, 148x12mm axle standard, BB92 bottom bracket standard, MUK 33 Hanger
Suspension Fork
Marzocchi Z2, Air, 130mm suspension travel, Tapered, 44mm fork offset, 29x2.6" max. wheelsize
Rear Shock
Rock Shox Deluxe Select+, lockout
Drivetrain
Rear Derailleur
Shimano XT M8100 Shadow+, SGS
Shift Levers
Shimano SL -MT500-IL / Shimano Deore M6100
Cassette
Shimano Deore M6100, 10-51 teeth, 12 speed
Crank
Race Face Ride, 32 teeth, 170 mm-S, 175 mm-M up
Bottom Bracket
Race Face BB BB92– Ø24mm
Chain
KMC X12
Wheels
Front Hub
Shimano MT400-B / Shimano MT410-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano MT400-B / Shimano MT410-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA EXPERT TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Spokes
Double Butted Black stainless
Tires
Front: Maxxis Forekaster, 29x2.35", fold, TR EXO Dual, Rear: Maxxis Forekaster, 29x2.35", fold, TR EXO Dual
Brakes
Brakes
Shimano M6100, 2 piston
Cockpit
Stem
MERIDA EXPERT TR, material: aluminium, 35mm diameter, 0° stem angle, 50 mm
Handlebar
MERIDA EXPERT TR, material: aluminium, 760mm width, 20mm rise
Headset
FSA NO.47/50
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA COMP TR, 30.9mm diameter, 0mm setback, S: 100mm travel seatpost - M: 125mm travel seatpost - L/XL: 150mm travel seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.35 mm |
| Bottom Bracket Height | 334 mm | 334 mm |
| Front Center | 729 mm | 753 mm |
| Rake | 51 mm | 52 mm |
| Trail | 101 mm | 100 mm |
| Stack | 613 mm | 622 mm |
| Reach | 441 mm | 461 mm |
| Top Tube Length | 598 mm | 620 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° |
| Seat Tube Length | 440 mm | 480 mm |
| Head Tube Angle | 67.3 ° | 67.3 ° |
| Head Tube Length | 95 mm | 105 mm |
| Chainstay Length | 441 mm | 441 mm |
| Wheelbase | 1167 mm | 1191 mm |
| Bottom Bracket Drop | 40 mm | 40 mm |
| Standover Height | 736 mm | 765 mm |
| Wheels | 29" | 29" |
About this model
ONE-TWENTY 600 is part of the Merida One Twenty model. Merida released 86 bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Merida ONE-TWENTY RC 300 2023 is the cheapest bike model and costs 1528$. Merida ONE-TWENTY 600 2023 is the most expensive one and costs 2919$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2919$. Comparing this to the average Trail bike price, we see that the price is 5.68% more expensive.
ONE-TWENTY 600 components
Fork
The fork installed on this bike is the Marzocchi Bomber Z2 model. The travel on this model is 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
From the factory, it comes with the Rock Shox Deluxe Select+ rear shock model, which has a travel of 120mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When leaving the production line, the ONE-TWENTY 600 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida ONE-TWENTY 600 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Dropper post
Merida ONE-TWENTY 600 comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
